BC807W

Name: BC807W - Communica [Part No: BC807W]
Brand: Communica
SKU: BC807W
Price: 0.37 ZAR
Availability: InStock

SKU: BC807W

BRAND: Communica

R 0.43_{(inc VAT)}
R 0.37_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Semiconductors

Type: Transistors

Category: PNP General Purpose Transistor

PNP VCBO = =50V VCEO = -45V IC = -500MA ICM = -1A 200MW SOT323

Specifications

Maximum DC Collector Current Idc	-500mA
Maximum Collector Emitter Voltage Vceo	-45V
Package Type	SOT-323
Mount Type	Surface
Transistor Configuration	Single
Maximum Collector Base Voltage VCBO	-50V
Transistor Polarity	PNP
Maximum Power Dissipation Pd	200mW
Minimum DC Current Gain hFE	100
Maximum Transition Frequency ft	100MHz
Minimum Operating Temperature	-65°C
Maximum Emitter Base Voltage VEBO	-5V
Pin Count	3
Maximum Operating Temperature	150°C
Width	2.2 mm
Series	BC807
Standards/Approvals	RoHS
Length	2.1mm
Height	1.1mm

Discover the powerful BC807W PNP transistor, perfect for your electronic projects. With a maximum collector current of -500mA and a voltage rating of -45V, it ensures reliable performance and efficiency. Ideal for surface mounting, this compact transistor excels in demanding applications, providing stability and durability in a variety of environments. Boost your designs with the BC807W's high gain and fast transition frequency!
