Electrical Characteristics

• Temp Range : -10 °C~100 °C
• Rated Power:
  • Curve B:O.125W
  • Other Curve B:0.053W
• Resistance Range : 10KΩ
• Allow Desistance Tolerance : ±20%(1MΩ or more30%)
• Rotation Noise : ≤47mV
• Terminal Resistance :
• R≥250KΩ 0.1%R max
• 250KΩ>R>10KΩ 20Ω max
• 10KΩ≥R 10Ω max
• Resistance Law : A, B, C
• Dielectric : AC500V, 1minnute
• Insulation Resistance : More than 100MΩ at DC500V

Mechanical Characteristics

• Rotational Toeque : 2~20 mN.m (20~200gf.cm)
• Total Rotational Angle : 300° ± 50°
• Rotary Life : 10,000 cycles
• Shaft Stopper Strength : 6Kgf.cm
• Push Pull Strength : 60 N
• Click position : Center detent or 10,20,40 position clicks
• Soldering : 235°C±5°C :≤3s
