HKV DS-2FA1225-C4

Name: HKV DS-2FA1225-C4 - Communica [Part No: HKV DS-2FA1225-C4]
Brand: Hikvision
SKU: HKV DS-2FA1225-C4
Price: 160 ZAR
Availability: InStock

SKU: HKV DS-2FA1225-C4

BRAND: Hikvision

R 184.00_{(inc VAT)}
R 160.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Security, Access Control & Surveillance

Type: CCTV Products & Accessories

Category: CCTV Accessories, CCTV Power Supplies

Hikvision 4CH Switch Mode Power Supply 48W, 12V 1A Per Channel 144×80x33mm

4CH Switch Mode Power Supply

Features

48 W, 12 VDC/1 A per channel
Over current/short circuit/over voltage protection
Good EMC performance
Compact size; applicable to cameras
150 to 285 VAC wide voltage input

Specifications

Appearance : White
Input : 150 to 285 VAC, 47 Hz to 63 Hz
Output : 12 VDC/1 A per channel
Cable Length Compensation
- Normal: 12 VDC
- Long: 13.5 VDC
- Ex-Long: 15 VDC
Ripple & Noise : 0.15 Vp-p (150 mV)
AC Input Connector : C4
DC Output Connector : DC Plug: grid terminal
LED Indicator : Green
Operating Conditions : 0°C to 40°C (32°F to 104°F), Humidity: 10% to 95% (non-condensing)
Storage Conditions : -40°C to 80°C (-40°F to 176°F), Humidity: 5% to 95% (non-condensing)
Dimension : 144 mm × 80 mm × 33 mm (5.67" × 3.15" × 1.30")

Downloads

Datasheet - HKV DS-2FA1225-C4

Additional Information

Device	Power Supply
Type	4CH \| Switch Mode

Power your security cameras with the HKV DS-2FA1225-C4, a reliable 4CH Switch Mode Power Supply delivering 48W and 12V, 1A per channel. Compact and efficient, it offers over current, short circuit, and over voltage protection, ensuring your devices stay safe and operational. Upgrade your security setup with this essential power supply for dependable performance and peace of mind.
