Hikvision Mobile Network Camera 2MP, Upto 30m IR, 1/2.8″ Progressive Scan CMOS, 3D DNR, (-I/ND): RJ45 Interface PoE: (802.3af, 36V~57V) Max10W, 120dB, Upto 256GB On Board Storage, User/Host:Upto 32 Users, IR Wavelength:850nm, IP68
2MP Mobile Network Camera
Feature(s)
- High quality imaging with 2MP resolution
- Clear imaging against strong back light due to 120 dB true WDR technology
- Efficient H.265+ compression technology
- Water and dust resistant (IP68,IP69K) and vandal proof (IK10)
- Advanced streaming technology that enables smooth live view and data self-correcting in poor network
- 3D DNR technology delivers clean and sharp images
Specifications
Selection Parameter
- Min. Illumination : 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- On-Board Storage : Up to 256 GB
- Protection Level : IP68, IP69k, IK10
- Wi-Fi Support : No
- Appearance Style Wedge
- Resolution : 2MP
- Lens Type : Fixed Lens
- Encoding : H.265+, H.265, H.264+, H.264
Camera
- P/N : P/N
- Sensor : 1/2.8′′ Progressive Scan CMOS
- Protection Level : IP68, IP69k, IK10
- Shutter Speed : 1/3 s to 1/100, 000 s
- Slow Shutter : Yes
- Wide Dynamic Range : 120 dB
- Day & Night : IR Cut Filter
- Angle Adjustment 2.8mm: pan: -15° to 15°, tilt: 15° to 30°, rotate: -90° to 90°
Lens
- Focal Length & FOV : 2.8mm: horizontal FOV 105°, vertical FOV 56°, diagonal FOV 126°
- Lens Mount : M12
- Aperture 2.8mm/4mm/6mm: F1.6
Illuminator
- Smart Supplement Light : Support
- IR Wavelength : 850 nm
- IR Range : Up to 30 m
Video
- Max. Resolution : 1920 × 1080
- Main Stream
- 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
- 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Sub-Stream
- 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
- 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)
- Third Stream
- 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288,
320 × 240)
- 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240,
320 × 240)
- Video Compression
- Main Stream: H.265 /H.264
- Sub-Stream: H.265 /H.264 / MJPEG
- Third Stream: H.265 /H.264
- Video Bit Rate
- Main Stream: 256 Kbps to 16 Mbps
- Sub-Stream: 256 Kbps to 4 Mbps
- Third Stream: 256 Kbps to 4 Mbps
- H.264 Type : Baseline Profile/Main Profile/High Profile
- H.265 Type : Main Profile
- Smart264 Type : Main Stream supports
- Smart265 Type : Main Stream supports
- Scalable Video Coding (SVC) : H.264 and H.265 encoding
- Region of Interest (ROI) : 1 fixed regions for each stream, and dynamic object tracking
Network
- Protocols : TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, SNMP, UDP, SSL/TLS, RTCP, ICMP, IGMP
- Simultaneous Live View : Up to 20 channels
- API : HIKSDK, ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI
- User/Host
- Up to 32 users
- 3 levels: Administrator, Operator and User
- Web Browser : Plug-in required live view: IE8+
- SmartIR : No
- Image Settings : Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client
- software or web browser
- Day/Night Switch : Day/Night/Auto/Schedule
- SNR : >50 dB
- Image Enhancement : BLC, HLC, 3D DNR, Defog, EIS
- Privacy Mask : 4 regions of privacy mask
- Picture Overlay : LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
- Digital Noise Reduction : 3D DNR
Interface
- Ethernet Interface
- Without -M: 1 RJ45 10M/100M self-adaptive Ethernet port
- -M: 1 four-core M12 aviation plug
- SD Card Extension : Yes
- Audio : No
- Alarm : No
- RS-485 : No
- Reset Key : Yes
- Heater : Yes
Event
- Basic Event Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, TF card error
- Smart Event
- Line crossing detection,
- Intrusion detection,
- Region entrance detection,
- Region exiting detection,
- Unattended baggage detection,
- Object removal detection,
- Object detection: detects faces and upload images
- Scene change detection, defocus detection
- Linkage : Upload to FTP/NAS/memory card, notify monitoring center, send email, trigger recording, trigger capture
General
- Power Interface Type
- -I/ND: RJ45 interface, PoE power supply
- -ID: Ø 5.5mm coaxial power plug, DC power supply
- -IDM: two-core Molex connector, DC power supply
- -IM/ND: four-core M12 aviation plug, PoE power supply
- Power Supply
- -ID, -IDM: 9-36 V, two-core terminal block, reverse polarity protection&PoE802.3af;
- -I/ND, -IM/ND: PoE: 802.3af, Type 1 Class 3
- Camera : Material Metal
- Camera Dimension
- Camera: 163.7 × 122.6 × 65.1 mm (6.4" × 4.8" × 2.6")
- With package: 252 × 190 × 108 mm (9.9" × 7.5" × 4.3")
- Camera Weight
- Camera: Approx. 905 g (2.0 lb.)
- With package: 1271 g (2.8 lb.)
- Startup and Operating Conditions : -40°C to 75°C (-40°F to 167°F). Humidity 95% or less (non-condensing)
- Language : upport English, German, French and Russian
- General Function : Anti-flicker, 3 streams, heartbeat, mirror, privacy mask
- Power Consumption
- -ID, -IDM: 9~36 V DC, max. 10 W
- -I/ND, -IM/ND: PoE: (802.3af, 36 V to 57 V), max. 10 W
