• Hik-Connect mobile control
• HD TVI video quality
• 7 inch touch screen
• Plug & Play

Door station/Video parameters

• Supplement light : IR light, up to 3 m
• Resolution : Stream resolution:1280 * 720@60fps
• FOV : Horizontal: 117°, Vertical: 70°, Diagonal: 141°

Door station/Audio parameters

• Audio input : 1 built-in omnidirectional microphone
• Audio output : 1 built-in loudspeaker

Door station/Capacity parameters

• Linked indoor station capacity : 3
• Sub door station capacity : 1
• Card capacity : /

Door station/Device interfaces

• Lock control : 1 relay, max 30 V 1 A
• Power supply input : 12 VDC
• Debugging port : 1
• Four-Wire interface : 1

Door station/General

• Button : 1 physical button(s)
• Indicator : /
• Power supply : 12 VDC
• Power consumption : ≤ 4 W
• Working temperature : -30 °C to 60 °C (-22 °F to 140 °F)
• Working humidity : 10% to 90% (no-condensing)
• Application environmentOutdoor
• Dimension (W × H × D) : 55 mm × 145 mm × 24 mm (2.17" × 5.71" × 0.94")
• InstallationSurface mounting
• Protective level : IP65, IK08
• Material : Aluminum alloy and Plastic
• Weight : Without package: 200 g (0.44 lb)

• Indoor station/System parameters
• Operation systemEmbedded Linux operation system
• RAM : 128 MB
• ROM : 32 MB
• Processor : Embedded high performance processor

Indoor station/Display parameters

• Type : Colorful TFT
• Resolution : 1024 × 600
• Viewing Angle : Horizontal 160°, vertical 130°
• Contrast : 700 (Typ)
• Luminance : 250 cd/m² （Typ）
• Operatiing method : Capacitive touch screen
• Screen size : 7-inch

Indoor station/Audio parameters

• Audio input : 1 built-in omnidirectional microphone
• Audio output : 1 built-in loudspeaker
• Audio compression bitrate : 64 Kps
• Audio compression standard : G.711U, G.711A
• Audio quality : Noise suppression and echo cancellation

Indoor station/Capacity parameters

• Linked network camera capacity : /
• Linked indoor extensions capacity : 2
• Linked doorphone capacity : 2
• Linked analog camera : 1

Indoor station/Network parameters

• Wi-FiWi-Fi 802.11 b/g/n

Indoor station/Device interfaces

• Network interface : /
• RS-485 : /
• Alarm input : 2
• Alarm output : /
• Power supply input : 12 VDC
• TF card : Support TF card, up to 128 G
• Debugging port : 2
• Four-Wire interface : 4
• Relay : /

Indoor station/General

• Button : 0 physical button
• Power supply : 12 VDC
• Power consumption : ≤ 5 W
• Working temperature : -10 °C to 50 °C (14 °F to 122 °F)
• Working humidity : 10% to 90% (no-condensing)
• Dimension (W × H × D) : 175 mm × 113.5 mm × 18.1 mm (6.89" × 4.47" × 0.71")
• Installation : Surface mounting
• Application environmentIndoor
• Weight : Without package: 260 g (0.573 lb)
• Language : English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese (Brazil), Spanish, Hebrew, Romanian, Turkish, Estonian, Danish, Swedish, Norwegian, Finnish, Vietnamese, Croatian, Slovenian, Serbian, Arabic, Portuguese (Portugal), Lithuanian, Uzbek, Kazakh, Mongolian, Ukrainian, Latvian, Traditional Chinese
