• High quality imaging with 2 MP resolution
• 24/7 colorful imaging
• Support Human and Vehicle Detection
• Water and dust resistant (IP67) and vandal resistant (IK08)
• Efficient H.265+ compression technology

Camera

• Image Sensor : 1/2.8" Progressive Scan CMOS
• Max. Resolution: 1920 × 1080
• Min. Illumination: Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
• Shutter Time : 1/3 s to 1/100,000 s
• Day & Night : 24/7 color imaging
• Angle Adjustment : Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°

Lens

• Lens Type : Fixed focal lens, 2.8
• Focal Length & FOV : 2.8 mm, horizontal FOV: 106°, vertical FOV: 57°, diagonal FOV: 126°
• Lens Mount : M12
• Iris Type : Fixed
• Aperture : F1.0
• Depth of Field : 2.8 mm: 1.5 m to ∞

DORI

• DORI : 2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m

Illuminator

• Supplement Light Type : White Light
• Supplement Light Range : Up to 30 m
• Smart Supplement Light : Yes

Video

• Main Stream
  • 50 Hz:
  • 25 fps (1920 × 1080, 1280 × 720)
  • 60 Hz:
  • 30 fps (1920 × 1080, 1280 × 720)
• Sub-Stream
  • 50 Hz: 25 fps (640 × 480, 640 × 360)
  • 60 Hz: 30 fps (640 × 480, 640 × 360)
• Video Compression
  • Main stream: H.265+/H.265/H.264+/H.264,
  • Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate : 32 Kbps to 8 Mbps
• H.264 Type : Baseline Profile,Main Profile,High Profile
• H.265 Type : Main Profile
• Bit Rate Control : CBR,VBR
• Region of Interest (ROI) : 1 fixed region(s) for main stream

Network

• Security : Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface，security audit log, host authentication (MAC address)
• Simultaneous Live View : Up to 6 channels
• API : Open Network Video Interface (Profile S, Profile T),ISAPI,SDK
• Protocols : TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
• User/Host
  • Up to 32 users
  • 3 user levels: administrator, operator, and user
• Client : iVMS-4200,HiLookVision
• Web Browser
  • Plug-in required live view: IE 10, IE 11,
  • Local service: Chrome 57.0+, Firefox 52.0+


• Wide Dynamic Range (WDR) : Digital WDR
• SNR : ≥ 52 dB
• Day/Night Switch : Day,Night,Auto,Schedule
• Image Enhancement : BLC,HLC,3D DNR
• Image Settings : Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Privacy Mask : 4 programmable polygon privacy masks

Interface

• Ethernet Interface : 1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

• Basic Event : Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• Linkage : Upload to FTP,send email,notify surveillance center,trigger capture

General

• Power
  • 12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug,
  • PoE: 802.3af, Class 3, 36 V to 57 V, 0.15 A to 0.2 A, max. 6.5 W
• Material : Base: aluminum alloy, cover: plastic
• Dimension : Ø121.5 mm × 97.6 mm (Ø4.8 × 3.8\")"
• Package Dimension : 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.9")
• Weight : Approx. 500 g (1.1 lb.)
• With Package Weight : Approx. 700 g (1.5 lb.)
• Storage Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language : English, Ukrainian
