• High quality imaging with 2 MP, 1920 × 1080 resolution
• 24/7 color imaging with F1.0 aperture
• 3D DNR technology delivers clean and sharp images
• 2.8 mm, 3.6 mm fixed focal lens
• Up to 20 m white light distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS)

Camera

• Image Sensor : 2 MP CMOS
• Max. Resolution : 1920 (H) × 1080 (V)
• Signal System : PAL/NTSC
• Frame Rate
  • TVI: 1080p@25fps/30fps
  • CVI: 1080p@25fps/30fps
  • AHD:1080p@25fps/30fps
  • CVBS: PAL/NTSC
• Min. Illumination : 0.001 Lux @ (F1.0, AGC ON)， 0 Lux with white light
• Shutter Time : PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Lens Mount : M12
• Light Alarm : Solid Light Alarm (White Light)
• Day & Night : 24/7 Color Imaging
• Angle Adjustment : Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°

Lens

• Lens Type : 2.8 mm fixed focal lens
• Focal Length & FOV : 2.8 mm, horizontal FOV: 102°, vertical FOV: 54°, diagonal FOV: 121°

Illuminator

• Supplement Light TypeWhite Light


• Image Parameters Switch : STD/HIGH-SAT/HIGHLIGHT
• Image Settings : Brightness;Contrast;Mirror;Defective Pixel Correction;Sharpness;Anti-Banding;Smart Light
• Wide Dynamic Range (WDR) : Digital WDR
• Image Enhancement : DWDR;BLC;HLC;Global
• White Light : Auto/Off
• AGC : Yes
• Day/Night Mode : Color
• White Balance : Auto/Manual
• Noise Reduction : 3D DNR/2D DNR
• Language : English

Interface

• Video Output : Switchable TVI/AHD/CVI/CVBS

General

• Operating Condition : -40°C to 60°C (-40°F to 140°F), humidity: 90% or less (non-condensing)
• Power Supply
  • 12 VDC±25%
  • *You are recommended to use one power adapter to supply the power for one camera.
• Consumption : Max. 2.4 W
• Material : Plastic
• White Light Range : Up to 20 m
• Dimension : Ø 85.4 mm × 71.46 mm (Ø 3.36" × 2.79")
• Weight : Approx.123 g (0.27 lb)

1. Datasheet - HLK THC-T129-P 2.8MM
