HQ-021-MC

Name: HQ-021-MC - Communica [Part No: HQ-021-MC]
Brand: Wain
SKU: HQ-021-MC
Price: 251.64 ZAR
Availability: InStock

SKU: HQ-021-MC

BRAND: Wain

R 289.39_{(inc VAT)}
R 251.64_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Connectors

Type: Power Connectors

Category: Heavy Duty Power Connector Inserts & Modules

Series Q21/0 (C) Insert 21P - Size 3A - Male Crimp Termination 6,5A/50V = 09120213001

Series Q21/0 (C) Insert 21P

Specifications

Product parameters

Inserts
Number of contacts	21
Electrical data acc. to EN 61 984
-Rated current	6.5A
-Rated voltage	50V
-Rated impulse voltage	0.8KV
-Pollution degree	3
Rated voltage AC	50V
Rated voltage DC	120V
Insulation resistance	≥10¹⁰Ω
Material	polycarbonate
Limiting temperatures	-40℃...+125℃
Flammability acc. to UL 94	V0
Mechanical working life(mating cycles)	≥500
Contacts
Material	copper alloy
Surface	hard-silver plated
Surface	hard-gold plated
Contact resistance	≤3mΩ
Crimp terminal
---mm²	0.09-0.52mm²
---AWG	28-20

Downloads

HQ-021-MC-Datasheet

Additional Information

Device	Insert
Type	Series Q21/0 (C) \| 21P \| Size 3A

Upgrade your connections with the HQ-021-MC Series Q21/0 (C) Insert. Designed for durability and efficiency, this male crimp termination supports 6.5A at 50V, ensuring reliable performance in any application. With a robust polycarbonate build and high insulation resistance, it withstands extreme temperatures and delivers long-lasting reliability. Perfect for your electrical needs!
