KLEPS250 BLACK - Test Leads & Probes -
KLEPS250 BLACK - Test Leads & Probes -
KLEPS250 BLACK - Test Leads & Probes -
KLEPS250 BLACK - Test Leads & Probes -

KLEPS250 BLACK

SKU: KLEPS250 BLACK

BRAND: SKS Hirschmann


In Stock
R 285.20 (inc VAT)
R 248.00 (ex VAT)

Collections: SKS Hirschmann, Test & Measurement

Type: Test Leads & Probes

Category: Test Probes

4mm Clamp type Test Probe • Black • Rotating grip jaws

Overview

Contact-protected clamp-type test probe with rotating grip jaws and flexible shaft. The grip jaws allows clamping of pins and wires up to a max. of 4 mm diameter. Brass 4 mm diameter contact-protected socket connection. Connects with sliding sleeve measuring leads.

Features

Rotating grip jaws

Specification



connection unsprung socket 4 mm
rated voltage(1) 30 VAC / 60 VDC
measurement cat. acc. to IEC 61010 O (3)
rated current(1)
(consider derating curve)		 4 A
material socket brass
housing material PA
temperature range acc. To IEC61010(2) -25 °C to +70 °C
inflammability class acc. to UL 94
(only valid for basic material of housing) 		V-0
clamp type rotating grip jaws, tin plated
clamping range 4 mm
standard IEC 61010

(1) for normal environmental conditions -5°C to +40°C
(2) contact the manufacturer for applications at deviating temperature ranges
(3) without rated measurement category, for other circuits that are not directly connected to mains
