KPSE02E-14-12SW - MIL-Spec / MIL-Type -

KPSE02E-14-12SW

SKU: KPSE02E-14-12SW

BRAND: Cannon


Sold Out

Collections: Connectors

Type: MIL-Spec / MIL-Type

Category: Circular MIL Spec Connectors

Circular Connctor Bayonet Lock Square Flinge Receptacle 12P Female 'W' Orientation Crimp MIL-C- 26482 Series. 1

Circular Connctor Bayonet Lock Square Flinge

Specifications

  • Sealing : Sealed
  • Shielding : Yes
  • Connector Type : Circular
  • Connector Style : Receptacle
  • Mounting Type : Box - Front Mount - Thru Holes
  • Contacts, # of : 12
  • Contact Style : Socket
  • Termination Method : Crimp
  • Crimp Wire Gauge : 24,22,20,18,16
  • Insert Arrangement : 14-12
  • Contact Size : 8#20,4#16
  • Contacts Supplied : Yes
  • Contact Material : Copper Alloy
  • Contact Plating : Gold
  • Shell Material : Aluminum Alloy
  • Shell Plating : Olive Drab Chromate over Cadmium
  • Shell Color : Olive Drab
  • Insert Material : Neoprene
  • Grommet & Seals Material : Neoprene
  • Amperage Rating : 13A & 22A
  • Operating Voltage AC V RMS Max : 600
  • Operating Temperature °F (°C) : -67 to +257 (-55 to +125).
  • Contact Mating Life : 500
  • Insert Rotation/Keying : W
  • Operating Voltage DC : 850
  • Orientation : Straight
  • Service Rating : I
  • Rotation Angle : 14
  • Endbell Type : Grommet Nut
  • Export Class : EAR / EAR99
  • RoHS : No
  • Weight (lbs) : 0.04084
  • Weight (g) : 18.53300

Downloads

Additional Information

Device Connctor
Type Circular | Bayonet Lock | Square | Flinge
