Overview
LI60-20B15PR2 is Mornsun’s AC-DC converter featuring a cost-effective, energy efficient solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise, compliant with international IEC62368 standards for EMC are safety approved to IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368 and EN62368. These light weight AC-DC converters also have an extremely compact design for space saving and are ideal for applications such as industrial control equipment machinery and all kinds of applications in a harsh environment.
Feature
- Universal 85 - 264VAC or 120 - 370VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +70℃
- High I/O isolation test voltage up to 4000VAC
- Industrial product technology design
- Over-voltage class III (Designed to meet EN61558 safety standards)
- Low standby power consumption, high efficiency
- Low ripple & noise
- Output short circuit, over-current, over-voltage protection
- Withstand 300VAC surge input for 5s
- EN62368safety approved
Specifications
| Type |
DIN Rail Single Output |
| Output Power |
60W |
| Series |
LI60-20B |
| Part Number |
LI60-20B15PR2 |
| Mount |
DIN-Rail |
| IP Level |
Non-Waterproof |
| Output Voltage |
15V |
| Output Current |
4A |
| Input voltage range |
85-264VAC; 120-370VDC |
| Inrush current (max.) |
Cold start, 60A at 230VAC |
| Output voltage adjustable range |
13.5-18V |
| Efficiency at 230VAC |
89% |
| Max. capacitive load |
80000µF |
| Input current (max.) |
0.8A at 230VAC |
| Short circuit protection |
Hiccup, continuous, self-recovery |
| Over-current protection |
≥120% Io, self-recovery |
| Withstand voltage |
300VAC |
| Working temperature |
-40 - 70°C |
| Connection |
Terminal block |
| Package dimensions |
92.66 x 52 x 58 mm |
| Weight |
175 gm |
| Cooling method |
Free air convection |
| Case material |
Plastic, heat-resistant (UL94V-0) |
| MTBF |
>300000 Hrs |
| Safety class |
CLASS II |
| Safety standards |
UL62368/EN62368/IEC62368 |
| EMC standards |
CISPR32/EN55032 CLASS B, CISPR32/EN55032 CLASS B, IEC/EN61000-4-3 10V/m |
| Certification |
CE, RoHS |
Downloads
Additional Information
| Device |
Power Supply |
| Type |
Plastic Case | Switch Mode |
