LI75-20B12R2S

SKU: LI75-20B12R2S

BRAND: Mornsun


DIN Rail Metal Case Slim Profile Switch Mode Power Supply Input: 90 ~ 264VAC/120 - 370VDC. Output 12VDC @ 6,3A 4KVAC Isolation (NDR-75-12)

Switch Mode Power Supply

Overview

LI75-20B12R2S is Mornsun AC-DC converter series featuring a cost-effective, energy efficient green power supply solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. These light weight AC-DC converters have an extremely compact design and the standard rail installation for space saving. With good EMC performance, compliant with international UL61010, EN62368 standards for EMC and safety

Feature

  • Universal 90 - 264VAC or 120 - 370VDCInput voltage
  • Accepts AC or DC input (dual-use of same terminal)
  • Operating ambient temperature range: -30℃to+70℃
  • High I/O isolation test voltage up to 4000VAC
  • Low ripple & noise
  • Output short circuit, over-current, over-voltage, over-temperature protection
  • DIN rail TS-35/7.5 or 15 mountable
  • Suitable for small chassis and narrow space installation
  • Safety according to UL61010, BS EN62368

Specifications

Type DIN Rail Single Output
Output Power 75.6W
Series LI75-20B
Part Number LI75-20B12R2S
Mount DIN-Rail
IP Level  Non-Waterproof
Output Voltage 12V
Output Current 6.3A

Downloads

Additional Information

Device Power Supply
Type Metal Case | Slim Profile | Switch Mode
