LIF120-10B12R2

SKU: LIF120-10B12R2

BRAND: Mornsun


DIN Rail Metal Case Switch Mode Power Supply with Active PFC. Input: 85 ~ 264VAC/120 - 370VDC. Output 12VDC @ 10A Hi Reliability (SDR-120-12)

Metal Case Switch Mode Power Supply

Feature

  • Universal 85 - 264VAC or 120 - 370 VDC Input voltage
  • Accepts AC or DC input (dual-use of same terminal)
  • Operating ambient temperature range: -40℃ to +70℃
  • High efficiency up to 94%, high reliability
  • DC OK function
    Active PFC
  • 150% peak load output for 3 seconds
  • DC ON output status indicator LED
  • Output short circuit, over-current, over-voltage,
    over-temperature protection
  • Operating altitude up to 5000m
  • OVCⅡ
  • Indoor use
  • Safety according to IEC/UL/BS EN 62368

Downloads

Additional Information

Device Power Supply
Type Metal Case | Switch Mode
Input Voltage 85 ~ 264VAC/120 - 370VDC
Output 12VDC @ 10A
