LKT STEPPER ACTUATOR 300MM 700N - Solenoids & Actuators -

LKT STEPPER ACTUATOR 300MM 700N

Name: LKT STEPPER ACTUATOR 300MM 700N - Communica [Part No: LKT STEPPER ACTUATOR 300MM 700N]
Brand: Communica
SKU: LKT STEPPER ACTUATOR 300MM 700N
Price: 1213.04 ZAR
Availability: OutOfStock

SKU: LKT STEPPER ACTUATOR 300MM 700N

BRAND: Communica

Sold Out
R 1,395.00_{(inc VAT)}
R 1,213.04_{(ex VAT)}

Collections: Electromechanical

Type: Solenoids & Actuators

Category: Stepper Actuators

Stepper Motor Linear Actuator. Stroke 300mm. Speed 8mm/S. LOAD 700N. Installation Size (Retracted) 405mm. Voltage 12 – 24VDC. Protection Grade IP43

Stepper Motor Linear Actuator

Specifications

Actuator

Travel or Stroke (S) Length: 300mm
Voltage: 12Vdc to 24Vdc (power supply input to servo drive)
Torque: 700N
Speed: 8mm/sec (no load)
IP43
Aluminium outer tube and stroke rod
Duty cycle: 10%

Stepper Motor

Phase: 2
Step angle: 1.8 degrees (200 steps per revolution)
Voltage: 2.8V
Current: 1.68A
Resistance: 1.65 ohms
Inductance: 2.3mH
Holding torque: 5 kg.cm
Insulation class: B

Stepper motor drive

Required, but not included
HKD STEPPER MOTOR DRIVER M542 is recommended

MODEL	STROKE (S)	INSTALLATION SIZE (L) {RETRACTED}	MAX - INSTALLATION {EXTENDED}	WEIGHT (KG)
LKT STEPPER ACTUATOR 300MM 700N	300mm	405mm	705mm	1.11kg

Additional Information

Device	Linear Actuator
Type	Stepper Motor

Upgrade your automation with the LKT Stepper Actuator 300mm 700N. This powerful linear actuator offers a smooth 300mm stroke and a robust load capacity of 700N, making it perfect for precise positioning in various applications. With a quick speed of 8mm/sec and durable aluminum construction, it ensures reliable performance and longevity. Elevate your projects with this versatile, efficient actuator today!
