LM100-23B24

Name: LM100-23B24 - Communica [Part No: LM100-23B24]
Brand: Mornsun
SKU: LM100-23B24
Price: 484.20 ZAR
Availability: InStock

SKU: LM100-23B24

BRAND: Mornsun

R 556.83_{(inc VAT)}
R 484.20_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Small Outline Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 24VDC @ 4,5A. Terminal Block Term. 4KVAC Isolation (LRS-100-24)

Small Outline Switch Mode Power Supply

Overview

LM100-23Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features universal AC input and at thesametimeaccepts DC input voltage, cost-effective, low no load power consumption, high efficiency and high reliability. These converters offerexcellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, EN60335, GB4943, EN61558 standards andtheyare widely used in areas of industrial, LED, street light control, electricity, security, telecommunications, smart home etc

Feature

Universal 85 - 305VAC or 120 - 430VDCinput voltage
Accepts AC or DC input (dual-use of sameterminal)
Operating ambient temperature range: -30℃to+70℃
Low standby power consumption, high efficiency
High I/O isolation test voltage up to 4000VAC
Low ripple & noise
Output short circuit, over-current, over-voltageprotection
OVC Ⅲ (designed to meet EN61558)
Operating up to 5000m altitude

Downloads

Datasheet-LM100-23Bxx

Additional Information

Device	Power Supply
Type	Small \| Outline \| Switch Mode
Size	129.00 x 97.00 x 30.00mm

The LM100-23B24 is a high-efficiency switch mode power supply designed for versatile applications, accepting both AC and DC inputs. With a compact metal case, it delivers 24VDC at 4.5A, ensuring reliable performance in industrial, telecommunications, and smart home systems. Experience exceptional reliability, low power consumption, and robust protection features, making it the perfect choice for your power supply needs.
