LM25-23B05

Name: LM25-23B05 - Communica [Part No: LM25-23B05]
Brand: Mornsun
SKU: LM25-23B05
Price: 225.66 ZAR
Availability: InStock

SKU: LM25-23B05

BRAND: Mornsun

R 259.51_{(inc VAT)}
R 225.66_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Small Outline Switch Mode Power Supply Input: 85 ~ 305VAC/100 - 430VDC. Output 5VDC @ 5A. Terminal Block Term. 4KVAC Isolation (RS-25-05) (Metal Case 5V - 5A)

Small Outline Switch Mode Power Supply

Feature

85 - 305VAC or 100 - 430VDC input voltage
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -30℃ to +70℃
Up to 88% efficiency
No-load power consumption < 0.5W
High I/O isolation test voltage up to 4000VAC
Output short circuit, over-current, over-voltage Protection
Over-voltage class Ⅲ (designed to meet EN61558)
Operating up to 5000m altitude

Additional Information

Device	Power Supply
Type	Small Outline \| Switch Mode
Input Voltage	85 ~ 305VAC/100 - 430VDC
Output	5VDC @ 5A
Size	80.00 x 55.00 x 25.00 mm

Experience reliable power with the LM25-23B05 Small Outline Switch Mode Power Supply. Designed for versatility, it supports both AC and DC inputs, delivering 5VDC at 5A with exceptional efficiency. Its robust construction ensures safety with high isolation voltage and built-in protection features, making it perfect for various applications up to 5000m altitude. Upgrade your power solutions today!
