LM35-23B24

Name: LM35-23B24 - Communica [Part No: LM35-23B24]
Brand: Mornsun
SKU: LM35-23B24
Price: 273.33 ZAR
Availability: InStock

SKU: LM35-23B24

BRAND: Mornsun

R 314.33_{(inc VAT)}
R 273.33_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over ZAR 1,000.00

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Small Outline Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 24VDC @ 1,5A. Terminal Block Term. 4KVAC Isolation

Small Outline Switch Mode Power Supply

Feature

Universal 85 - 264VAC or 120 - 370VDC input voltage
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -30℃ to +70℃
Low standby power consumption, high efficiency
High I/O isolation test voltage up to 4000VAC
Low ripple & noise
Output short circuit, over-current, over-voltage
protection
Over-voltage class Ⅲ (designed to meet EN61558)
Operating altitude up to 5000m

Downloads

Datasheet - LM35-20B24

Additional Information

Device	Power Supply
Type	Small Outline \| Switch Mode
Input Voltage	85 ~ 305VAC/120 - 430VDC
Output	24VDC @ 1,5A
Size	99.00 x 82.00 x 30.00 mm

Upgrade your power solutions with the LM35-23B24 Small Outline Switch Mode Power Supply. Featuring a versatile input range of 85-305VAC and 120-430VDC, it delivers reliable 24VDC output at 1.5A. With exceptional efficiency, low standby power consumption, and robust safety features, this compact power supply is perfect for your demanding applications. Enjoy peace of mind with high isolation voltage and temperature resilience from -30℃ to +70℃.
