LM350-10B48

Name: LM350-10B48 - Communica [Part No: LM350-10B48]
Brand: Mornsun
SKU: LM350-10B48
Price: 698.69 ZAR
Availability: OutOfStock

SKU: LM350-10B48

BRAND: Mornsun

Sold Out
R 803.49_{(inc VAT)}
R 698.69_{(ex VAT)}

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Small Outline Switch Mode Power Supply Input: 180 ~ 264VAC (Switch)/240 - 370VDC. Output 48VDC @ 7,3A. Terminal Block Term. Built-in DC Fan (LRS-350-48)

Small Outline Switch Mode Power Supply

Overview

LM350-10Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features selectable AC input and at the same time accepts DC input voltage, cost-effective, low no load power consumption, high efficiency and high reliability. These power supply offer excellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, EN60335, GB4943 standards and they are widely used in areas of industrial, LED, street light control, electricity, security, telecommunications, smart home etc.

Feature

Selectable AC input range: 90 - 132VAC/180 - 264VAC
DC input range: 240 - 370VDC
Ultra low standby power consumption < 0.75W @230VAC
Operating ambient temperature range: - 30℃ to +70℃
LED indicator for power on
Output short circuit, over-current, over-voltage, over-temperature protection
Built-in DC fan
Operating up to 5000m altitude

Downloads

Datasheet-LM350-10Bxx

Additional Information

Device	Power Supply
Type	Switch Mode \| Metal Case
Size	215.00 x 115.00 x 30.00m

The LM350-10B48 is a versatile metal-case switch mode power supply, delivering 48VDC at 7.3A with high efficiency and low standby consumption. Ideal for industrial, LED, and smart home applications, it ensures reliability, excellent EMC performance, and built-in protection features, making it your go-to solution for powering devices safely and effectively.
