LM350-22B12R2S

Name: LM350-22B12R2S - Communica [Part No: LM350-22B12R2S]
Brand: Mornsun
SKU: LM350-22B12R2S
Price: 647.69 ZAR
Availability: InStock

SKU: LM350-22B12R2S

BRAND: Mornsun

R 744.84_{(inc VAT)}
R 647.69_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Small Outline Switch Mode Power Supply Input: 180 ~ 264VAC (Switch)/240 - 370VDC. Output 12VDC @ 29A. Terminal Block Term. Built-in DC Fan (LRS-350-12)

Small Outline Switch Mode Power Supply

Overview

LM350-10Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features selectable AC input and at the same time accepts DC input voltage, cost-effective, low no load power consumption, high efficiency and high reliability. These power supply offer excellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, EN60335, GB4943 standards and they are widely used in areas of industrial, LED, street light control, electricity, security, telecommunications, smart home etc.

Feature

Selectable AC input range: 90 - 132VAC/180 - 264VAC
DC input range: 240 - 370VDC
Ultra low standby power consumption < 0.75W @230VAC
Operating ambient temperature range: - 30℃ to +70℃
LED indicator for power on
Output short circuit, over-current, over-voltage, over-temperature protection
Built-in DC fan
Operating up to 5000m altitude

Downloads

Datasheet-LM350-10Bxx

Additional Information

Device	Power Supply
Type	Small \| Outline \| Switch Mode
Size	215.00 x 115.00 x 30.00m

The LM350-22B12R2 is a high-efficiency switch mode power supply that delivers a reliable 12VDC @ 29A output. With its compact design, selectable AC/DC input, and built-in protection features, it ensures optimal performance for industrial applications, LED lighting, and smart home devices. Enjoy low power consumption and robust reliability, making it the perfect choice for your power supply needs.
