LMF1000-20B12

Name: LMF1000-20B12 - Communica [Part No: LMF1000-20B12]
Brand: Mornsun
SKU: LMF1000-20B12
Price: 4711 ZAR
Availability: OutOfStock

SKU: LMF1000-20B12

BRAND: Mornsun

Sold Out
R 5,417.65_{(inc VAT)}
R 4,711.00_{(ex VAT)}

Collections: Power

Type: Power Supplies

Category: Metal Case Power Supply, Switch Mode Power Supplies

Metal Case Switch Mode Power Supply with Active PFC. Input: 90 ~ 264VAC/120 - 430VDC. Output 12VDC @ 80A + 5V @ 2A. Built-in Variable Speed DC Fan

Metal Case Switch Mode Power Supply

Feature

Wide range Input voltage 90 - 264VAC or 120 - 370VDC
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -40℃ to +70℃
(Non-condensing)
High reliability, efficiency up to 94%
Wide range of adjustable output voltage
Output short circuit, over-current, over-voltage protection,
over-temperature protection
Support 3+1 parallel redundancy, current sharing
Built-in active PFC function
Operating up to 5000m altitude
Fan speed automatic adjustable
Safety according to IEC62368, ES/EN60601

Downloads

Datasheet - LMF1000-20B12

Additional Information

Device	Power Supply
Type	Metal Case \| Switch Mode
Input Voltage	90 ~ 264VAC/120 - 430VDC
Output	12VDC @ 80A + 5V @ 2A
Size	190.0 x 127.0 x 40.5 mm

Discover the LMF1000-20B12 Metal Case Switch Mode Power Supply, designed for exceptional reliability with 12VDC @ 80A output. Featuring wide input voltage compatibility and robust protection mechanisms, it ensures optimal performance in demanding environments. With an efficiency of up to 94% and built-in active PFC, this power supply is perfect for diverse applications, ensuring stability and safety at any altitude. Upgrade your power solution today!
