Digital Cable Length Meter, 60 000 Count Backlit LCD Display, Cable Length:0.1m~30.00km, Resistance:2000.0mΩ~2000Ω, Auto Power Off, Built-In-buzzer, 210x97x68mm, 634g
Digital Cable Length Meter
Overview
The MT933 is a Digital Cable Length Meter with a 60 000 count handheld battery operated metric cable length meter that quickly measures any reeled wire or cable up to 30 000m and with gauges ranging from 0.15mm² to 240mm². Within seconds cables can be measured and digitally displayed without the cumbersome task of unrolling cable reels. All that is needed is accessibility to both cable ends. The MT933 can also be used as a precision milliohm meter. The User Select Mode allows the user to save the resistance of a user wire for additional measurements of unknown lengths of the same wire gauge. In addition, it enables the user to accurately measure the length of standard gauge wire or cables. In this mode, the user can measure the length of any metal wire, resistance of which can be measured, as well as Copper or Aluminium cables. Temperature is also displayed on the large backlit LCD display. This instrument is very useful for Electrical Contractors, Utilities and Distributors for the control of inventories of cable.
Features
- 60 000 count backlit LCD display
- Measure up to 30 000m
- 20 pre-set wire gauge settings 0.15mm2 to 240mm2
- 8 memory locations in user select mode
- Automatic temperature compensation
- Measures Aluminium Al and Copper Cu cables and wire
- Measures and indicates Temperature
- User Calibration mode
- Measures in meters (m) and feet (ft)
- Kelvin clip test leads included
- Built-in buzzer
- Auto Power Off
Specifications
| Function |
Range |
Resolution |
Accuracy |
| Length Measurement |
1000m |
0.1m |
±(1% + 1m) |
| |
10 000m |
1m |
±(1% + 1m) |
| |
30 000m |
0.01km |
±(1.2% + 1m) |
| Resistance |
1999.9mΩ |
0.1Ω |
±(1% + 3) |
| |
19.999Ω |
0.001Ω |
±(1% + 0.5mΩ) |
| |
199.99Ω |
0.01Ω |
±(1% + 50mΩ) |
| |
1999.9Ω |
0.1Ω |
±(1% + 6) |
| Temperature |
-5 to 50°C |
0.1°C |
±(2% + 1.8°C) |
| Twenty Measurement Gears |
0.15mm², 0.25mm², 0.5mm², 0.75mm², 1mm², 1.5mm², 2.5mm², 4mm², 6mm², 10mm², 25mm², 35mm², 50mm², 70mm², 95mm², 120mm², 150mm², 185mm², 240mm² |
| Cable Library |
20 Standard Cable Types |
| Memory Location |
8 Memory Locations |
| Digital Display |
60 000 Count |
| Overrange Indication |
Yes |
| Back Light |
Yes |
| Enclosure |
Moulded Casing |
| Low Battery Indication |
Yes |
| Batteries |
6 x AA |
| Weight |
634g |
| Dimensions |
210 x 97 x 68mm |
| Safety Specs |
IEC61326 |
Downloads
Additional Information
| Device |
Length Meter |
| Type |
Digital Cable |
Discover the MAJ MT933 Digital Cable Length Meter, your ultimate tool for precise cable measurements up to 30,000m. With a vibrant 60,000 count backlit LCD display and 20 wire gauge settings, it streamlines the measuring process, making it effortless for contractors and utilities. Experience accuracy, memory features, and built-in temperature display—all in a compact, user-friendly design. Upgrade your cable management today!
