MAJ MT957 - Component Testers - 6008229030536

MAJ MT957

Name: MAJ MT957 - Communica [Part No: MAJ MT957]
Brand: Major Tech
SKU: MAJ MT957
Price: 2315 ZAR
Availability: InStock

SKU: MAJ MT957

BRAND: Major Tech

In Stock
R 2,662.25_{(inc VAT)}
R 2,315.00_{(ex VAT)}

Collections: Test & Measurement

Type: Component Testers

Category: LCR Meter

11 000 Count LCR Meter

LCR Meter

Overview

The MT957 11 000 Count LCR Meter is a battery operated and provides direct and accurate measurements of inductors, capacitors and resistors with different frequencies and is selectable for auto ranging or manual ranging. Convenient front panel push buttons and controls include functions such as data hold, maximum and minimum record mode and relative mode. The 11,000 count LCD display is backlit for easy reading in dark locations.

Features

Provides direct and accurate measurements of inductors, capacitors and resistors with different frequencies and is selectable for auto/manual ranging
11 000 Count LCD display
Min / Max
Relative mode
Measures inductance to 20H
Resistance 40MΩ
Capacitance

Specifications

Function	Range	Resolution	Accuracy
Resistance	100.0 – 40MΩ	0.01Ω	±(1.2% ± 0.5)
Capacitance	11.000nF – 110.00mF	1pf	±(5.0% ± 0.7pF)
Inductance	11.000mH – 20.00H	1μH	±(2.0% + 0.05mH)
Over Range Indication	Yes
Digital Display	11000 count LCD
Back Light	Yes
Diode Test	Yes
“O” Adj.	Yes
Min/Max	Yes
Relative Mode	Yes
Data Hold	Yes
Enclosure	Double moulded case
Low Battery Indication	Yes
Battery	9V
Weight	255g
Dimensions	150 x 70 x 48mm
Safety specs	IEC61010-1 CAT III 600V

Downloads

DataSheet

Additional Information

Keywords	major tech, MT957, lcr meter, lcr, meter
Device	LCR Meter
