Smart Energy Meter & Timer, 50/60Hz, Rated Current:65A , 9600W (Resistive Load), 110V/220V, kWh Accuracy:Class1, Voltage/Current Circuit:<1.5VA/<2W/8VA, 0.004Ib(20mA), LCD:99999.9kWh, WIFI:802.11B/G/N, Only Supports 2.4GHZ Network, Bluetooth V5.2
Smart Energy Meter & Timer
Overview
The MTS21 Smart energy meter & timer is specifically designed to measure active and reactive energy for single-phase two-wire systems and various parameters. This smart device is equipped with Wi-Fi connectivity, allowing users to utilize the free “Major Tech Hub” Smart App for remote monitoring and control. It adheres to Wi-Fi 802.11b/g/n standards for seamless data communication. When installing the smart device, ensure that this is done by a qualified professional in accordance with South African regulations and making sure it is placed in an appropriate environment with an ambient temperature range of -25°C to 55°C. The relative humidity should be kept below 75%. The manufacturing of this device aligns with international standards, including IEC62052-11 for General Requirements for Electricity Metering Equipment (AC) and IEC62053-21 for Static meters/timers for Active Energy (Classes 1 and 2). Features: Provides in-depth analysis of energy consumption via the smart app Displays Voltage, Current, Active Power, Power Factor and Frequency Load Protection – the app can be set to alert and trigger an automatic device shutdown Din Rail Compatible (35mm) Dual Mode: Wi-Fi and Bluetooth
Features
- Provides in-depth analysis of energy consumption via the smart app
- Displays Voltage, Current, Active Power, Power Factor and Frequency
- Load Protection – the app can be set to alert and trigger an automatic device shutdown
- Din Rail Compatible (35mm)
- Dual Mode: Wi-Fi and Bluetooth
- The MTS21 and Major Tech Hub App allow you to select a custom date range (up to 2 months) for energy consumption tracking, download the data in Excel format, and easily share it via third-party apps.
- Voice Compatible: Works with Alexa and Google Assistant for hands-free control
Specifications
| Function |
Range |
| Rated Frequency |
50/60 Hz |
| Rated Current |
65A |
| Power |
9600W (Resistive Load) |
| Rated Voltage |
110V/220V |
| Voltage Range |
90 – 260V |
| Approvals |
IEC/SANS / ICASA / LOA |
| kWh accuracy |
Class 1 |
| R.M.S accuracy |
Class 0.5 |
| Current circuit |
<1.5VA |
| Voltage circuit |
<2W/8VA |
| Starting Current |
0.004Ib(20mA) |
| LCD |
99999.9kWh |
| Operation Temp. |
-25°C to +55°C |
| Bluetooth |
Version 5.2 |
Downloads
Additional Information
| Device |
Meter & Timer |
| Type |
Smart | Energy |
The MAJ MTS21 Smart Energy Meter & Timer empowers you to monitor and manage your energy consumption effortlessly. With Wi-Fi and Bluetooth connectivity, track real-time data like voltage and power usage through the Major Tech Hub App. Enjoy enhanced load protection and voice control compatibility with Alexa and Google Assistant, making energy efficiency convenient and accessible for your home.
