MB3759
SKU: MB3759
BRAND: Communica
R 18.98 (inc VAT) R 16.50 (ex VAT)
🚚
Delivery time: 2-5 working days for South Africa
✓
In stock - Ready for immediate dispatch
Free shipping for orders over R1,000.00
Switching V/Reg Circuit 16p SOIC
Specifications
Device Type: Voltage Detector / Reset Controller
Technology: Bipolar Linear IC
General Features
Precision power supply monitoring
Automatic system reset generation
Brownout detection
Low external component count
Designed for microprocessor-based systems
Electrical Characteristics
Supply Voltage Range:
Reset Detection Voltage:
Approximately 4.0 V (typical)
Factory-trimmed threshold
Reset Delay Time:
Determined by external capacitor
Supply Current:
Reset Functions
Monitors VCC continuously
Generates reset signal during:
Power-up
Power-down
Supply voltage drop (brownout)
Ensures proper microprocessor initialization
Output Characteristics
Open-collector reset output
Direct interface to:
Microprocessors
Microcontrollers
Logic circuits
Protection Features
Power-failure detection
Brownout protection
False reset suppression
Noise immunity enhancement
Package
Package Type: DIP
Pin Count: 8 Pins
Mounting Style: Through-Hole
Operating Temperature
Operating Range: -20°C to +75°C
Typical Pin Functions
VCC
GND
Reset Output
Timing Capacitor
Voltage Sense
Reference
Control Input
Output Control
Additional Information
Ensure your microprocessor systems run smoothly with the MB3759 Voltage Detector and Reset Controller. Offering precision power supply monitoring, brownout protection, and automatic reset generation, this compact 16-pin SOIC device enhances reliability while minimizing external components. Ideal for various applications, it guarantees proper initialization and noise immunity, making it a vital addition to your electronic projects.
