MDR-20-24

SKU: MDR-20-24

BRAND: Meanwell


DIN Rail Plastic Case Slim Profile Switch Mode Power Supply Input: 85 ~ 264VAC/120 - 370VDC. Output 24VDC @ 1A - w/DC OK Feature (DIN Rail Plastic 24V 1A)

Switch Mode Power Supply Unit

Feature

  • Universal AC input/Full range
  • Protections: Short circuit/Overload/Over voltage
  • Cooling by free air convection
  • Can be installed on DIN Rail TS-35/7.5 or 15
  • DC OK relay contact
  • LED indicator for power-on
  • No load power consumption <0.75 W
  • 100% full load burn-in test
  • 3 years warranty
  • Class 1, Div 2 hazardous locations T4

Specifications

  • AC or DC Input Voltage : AC
  • AC or DC Output Voltage : DC
  • Input Voltage : 85 → 264V AC
  • Output Voltage : 24V DC
  • Output Current : 1A
  • Power Rating : 20W
  • Number of Outputs : 1
  • Electrical Phase : 1
  • Height : 100mm
  • Width : 22.5mm
  • Depth : 90mm
  • Output Voltage Adjustment Range : 24 → 30V
  • Series : MDR
  • Depth : 90mm
  • Mounting Type : DIN Rail Mount
  • Standards Met : RoHS Compliant, TUV EN 60950-1, UL 508
  • Minimum Temperature : +70°C
  • Load Regulation : ±1%
  • Maximum Temperature : +70°C
  • Ripple And Noise : 150mV Pk-Pk

Downloads

Additional Information

Device Power Supply Unit
Type Switch Mode
