| INPUT |
| Input Voltage Range |
55-150 VAC or 110-300 VAC (Based on load at 50%); 85-140VAC or 160-280VAC (Based on load at 100%) |
| Nominal Voltage |
100/110/115/120/127VAC or 200/208/220/230/240VAC |
| Frequency Range |
40Hz ~70 Hz |
| Power Factor |
>= 0.99 @ Nominal Voltage (100% load) |
| OUTPUT |
| Voltage Regulation |
± 1% |
| Output Voltage |
100/110/115/120/127VAC or 200/208/220/230/240VAC |
| Frequency Range (Batt. Mode) |
50 Hz ± 0.25 Hz or 60 Hz ± 0.3 Hz |
| Transfer Time : AC Mode to Battery Mode |
Zero |
| Transfer Time : Inverter to Bypass |
4 ms (Typical) |
| Transfer Time : Waveform (Batt. Mode) |
Pure Sine Wave |
| Current Crest Ratio |
3::1 |
| Harmonic Distortion |
-- 3% THD (Linear Load); -- 6% THD (Non-linear Load) |
| Frequency Range (Synchronized Range) |
47~53 Hz or 57~63 Hz |
| EFFICIENCY |
| Battery Mode |
0.88 |
| AC Mode |
0.9 |
| BATTERY |
| Long-run Model : Battery Type |
Depending on the capacity of external batteries |
| Long-run Model : Charging Current (max.) |
1A/2A/4A/6A (Adjustable) |
| Long-run Model : Charging Voltage |
82.1 VDC ± 1% ,109.4 VDC ± 1% |
| Long-run Model : Numbers |
6, 8 |
| Standard Model : Battery Type |
12 V / 9 AH |
| Standard Model : Charging Current (max.) |
1A |
| Standard Model : Charging Voltage |
82.1 VDC ± 1% |
| Standard Model : Numbers |
6 |
| Standard Model : Typical Recharge Time |
4 hours recover to 90% capacity |
| INDICATORS |
| LCD |
Load level, Battery level, AC mode, Battery mode, Bypass mode, and Fault indicators |
| ALARM |
| Battery Mode |
Sounding every 4 seconds |
| Low Battery |
Sounding every second |
| Overload |
Sounding twice every second |
| Fault |
Continuously sounding |
| ENVIRONMENT |
| Operating Humidity |
20~90% RH @ 0- 40°C (non-condensing) |
| Noise Level |
Less than 50dB @ 1 Meter |
| PHYSICAL |
| Standard Model : Dimension, D x W x H (mm) |
630 x 438 x 88 [2U] |
| Standard Model : Net Weight (kgs) |
29.3 |
| Long-run Model : Dimension, D x W x H (mm) |
410 x 438 x 88 [2U] |
| Long-run Model : Net Weight (kgs) |
14.2 |
| MANAGEMENT |
| Optional SNMP |
Power management from SNMP manager and web browser |
| Smart RS-232/USB |
Supports Windows 2000/2003/XP/Vista/2008, Windows 7/8/10, Linux, and MAC |
