MS3124E-14-15P

Name: MS3124E-14-15P - Communica [Part No: MS3124E-14-15P]
Brand: Souriau
SKU: MS3124E-14-15P
Price: 613 ZAR
Availability: InStock

SKU: MS3124E-14-15P

BRAND: Souriau

In Stock
R 704.95_{(inc VAT)}
R 613.00_{(ex VAT)}

Collections: Connectors

Type: MIL-Spec / MIL-Type

Category: Circular MIL DTL 26482 Connectors

Circular Connector MIL-DTL-26482 Series 1 Style Bayonet Lock Bulkhead Jam Nut Receptacle Male 15 Pole 14* #20/1* #16 Solder Contact 7,5A/22A 600VAC/850VDC (KPSE07E-14-15P)(PT07SE-14-15P)(85107R1415S50)

Circular Connector MIL-DTL-26482 Series

Specifications

Physical

Body Material : Aluminium
Contact Material : Copper
Contact Plating : Gold
Mount : Bulkhead, Front Side Nut, Jam Nut, Panel

Technical

Connector Type : Circular, Receptacle
Current Rating : 13 A
Fastening Type : Bayonet
Gender : Receptacle
Max Operating Temperature : 125 °C
Military Standard : MIL-C-26482
Min Operating Temperature : -55 °C
Number of Contacts : 15
Number of Positions : 15
Orientation : Straight
Packaging : Bulk
Termination : Crimp

Compliance

Radiation Hardening : No
Ratings : Environment Resistant
REACH SVHC : No SVHC
RoHS : Compliant

Downloads

Datasheet - MS3124E-14-15P

Additional Information

Device	Connector
Type	Circular \| MIL-DTL-26482
