NF-802 NETWORK CABLE TESTER - LAN/Telecom/Cable Testing -

NF-802 NETWORK CABLE TESTER

Name: NF-802 NETWORK CABLE TESTER - Communica [Part No: NF-802 NETWORK CABLE TESTER]
Brand: Noyafa
SKU: NF-802 NETWORK CABLE TESTER
Price: 1050 ZAR
Availability: InStock

SKU: NF-802 NETWORK CABLE TESTER

BRAND: Noyafa

In Stock
R 1,207.50_{(inc VAT)}
R 1,050.00_{(ex VAT)}

Collections: Test & Measurement

Type: LAN/Telecom/Cable Testing

Category: Network Cable Tester

Intelligent Network Cable Tester. Scan&WireMap. QC Test. Digital Signal Scanning. Multi-Function Testing Cable Mode. Port Flash. Withstand Voltage 60V. NCV Strong Current Detection. LED Light.

Intelligent Network Cable Tester

Features

Scan&Wiremap - Dual-use test mode. Wiremap operation can be performed in Scan mode.
QC Test - Accurately measure which end of the network cable is not crimped.
Digital signal scanning - Dedicated digital signal anti-interference.
Multi-function testing cable mode - Test cable pass/short circuit/open circuit/cross.
Port Flash - To locate network port by the flashing port light on a server/switch/hub/router port.
Withstand Voltage - Interface Withstand Voltage 60V, support POE scanning without burning.
NCV strong current detection - Quickly identify strong electricity in the work environment and provide safety guarantee.
LED lighting - Help you to scan the cables clearly in the dark room.
Super strong momentum - Built-in 1400mAh polymer lithium battery, Type-C Charge.
Certification - Passes RoHS, FCC, and CE compliance testing, and Noyafa is certified to the ISO 9001 standard.
100% Affordable - Manufactured in China and a lot cheaper than competitor products with similar quality.

Specifications

Types	Function	Instruction
Emitter	Suitable for network cable	CAT5 CAT6
	Anti-jamming scanning	√
	Low battery prompt	Below 3.3V+0.1V power indicator flashes
	scrimping response speed	<1s
	Power supply battery	3.7V,1400Ah Lithium polymer battery
	Stand-by current	Wiremap / SCAN/ QC< 25mA，Flash< 150mA
	Interface Type	RJ11、RJ45
	Dimension	60x135x30mm
Receiver	Suitable for network cable	CAT5 CAT6
	Sensitivity adjustment	√
	NCV	√
	lighting	√
	Headphone jack	√
	Wiremap	√
	Power supply battery	3.7V,1400Ah Lithium polymer battery
	stand-by current	≤35mA
	Maximum working current	≤280mA
	Dimension	50x198x30mm

Downloads

User Manual - NF-802 NETWORK CABLE TESTER

Additional Information

Device	Cable Tester
Type	Intelligent \| Network
