NF-912 PON OPTICAL POWER METER
SKU: NF-912 PON OPTICAL POWER METER
BRAND: Noyafa
R 2,850.00 (inc VAT) R 2,478.26 (ex VAT)
🚚
Delivery time: 2-5 working days for South Africa
✓
In stock - Ready for immediate dispatch
Free shipping for orders over ZAR 1,000.00
Passive Optical Network (PON) Optical Power Meter. Wavelength.Ont Uplink Signal Probe (1310NM). Wavelength.OLT/Video Downlink Signal Probe (1490/1550NM).
Passive Optical Network (PON) Optical Power Meter
Features
Wavelength.ONT Uplink signal probe (1310nm).
Wavelength.OLT/Video Downlink signal probe (1490/1550nm).
Quickly Diagnose the Network Problems.
Auto off Function, it can set for time and threshold.
Data Storage.
SC/FC general-purpose interface.
Certification. Passes RoHS, FCC, and CE compliance testing, and Noyafa is certified to the ISO 9001 standard.
100% Affordable. Manufactured in China and a lot cheaper than competitor products with similar quality.
Specifications
Type
NF-912
Calibration wavelength
1310 Uplink test
1490 Downlink Test
1550 Downlink Test
Passband (nm)
1260~1360
1480~1500
1535~1570
Detection range (dBm)
-35~+10
-50~+10
-50~+10
lsolation 1310nm (dB)
—
>40
> 40
lsolation 1490nm (dB)
>40
—
>40
lsolation 1550nm (dB)
>40
>40
—
Precision (dB)
± 0.5
Linearity
±2%
Fiber optic adapter
Optical fiber SC interface
Detector type
Yes
Battery type
3.7V/1440mAH lithium battery
Battery life (H)
>50
Use temperature
-10%~+50°C ， <90%RH
Storage temperature
-20%~+60°C ， <90%RH
Product size (mm)
182*105*50
Downloads
Additional Information
Device
Optical Power Meter
Type
Passive Optical Network (PON)
The NF-912 PON Optical Power Meter is your essential tool for diagnosing network issues quickly and efficiently. With precise measurement capabilities at 1310nm, 1490nm, and 1550nm, this affordable meter ensures reliable performance while meeting RoHS, FCC, and CE standards. Enhance your network maintenance with its data storage feature and user-friendly design.
