NVR XY-8208

• Use the standard H.264 video compression format stream lower,high quality,longer recording time, taking up less bandwidth resources*
• GUI OSD interface,USB Mouse controller,more intuitive,easier to use for user-friendly
• ONVIF standard protocol(Onvif agreement with standard)can be connected with the front –end IPC protocol support onvif.
• Support Strong cloud service,one step to do remote control easily
• Support 8CH 1080P* recording.
• Dual-stream design,network remote view effects and local recording effects parameters can be set separately,independently of each other.
• Hexaplex operation simultaneously:Preview,recording,playback,backup,network live,mobile phone view
• Multiple record mode:Auto continuous, timing recording* , motion detection , trigger alarm recording mode
• Recording playback support:Normal play, Speed play, Fast back play, Manual single-frame slow play
• Support drag the progress bar can be targeted playback time directly
• Support Multiple channel playback (Support 1CH 1080P playback simultaneously, each channel can be enlarge to full screen)
• Powerful net service:support IE browser(built -in)and sub-control software to monitor and manage network
• Strong network function:support DHCP/PPPOE/FTP/DNS/DDNS/NTP/UPNP/EMAIL/IP authority/IP search/alarm center,etc,complete enclosure (WEB/CMS/SDK),to easily achieve interconnection.
• Supports remote surveillance up to 10 users simultaneously via the Internet Explorer web browser
• Supports Multiple backup mode: USB flash drive,USB hard disk and network backup
• Support pre-alarm recording (before 10 sec),not lose any suspicious screen
• Support one SATA HDD
• Support Mobile phone remote view by Symbian;Windows Mobile;Android system;Iphone;Blackberry.
• Support High-Definition VGA and HDMI(1080P) output.

• Video Compression Format : H.264
• Video Standard : NTSC / PAL
• GUI OSD : YES
• Video Input : 8CH 1080P
• Video Output : 1CH VGA/HDMI output
• Image Quality Setting : Supper Best,Well,Very good,Well,Good Common
• Hard Disk Storage : Support one SATA HDD,
• Multiplex Operation : Live display/record/playback/backup/network transmit
• Recording Mode : Manual/Timer/Motion detection/alarm
• Playback Mode : Multiple slow and rapid play speeds,manual and single-frame play modes,and support of drag the sliding bar to set.
• Backup Device : USB flash drive,USB hard disk,USB and network backup
• Pre-alarm Recording : Recording for 10 seconds before alarming
• Network Protocol : TCP/IP/PPPOE/DDNS/FTP/NTP and UPNP
• Ethernet remote view : Support remote surveillance up to 10 users simultaneously
• CMS software : YES
• Mobilephone View : YES
• Electronic zoom : YES
• VGA Interface : YES
• Log record function : YES
• Image Tour : YES
• IR Remote control : YES
• Video Loss Detection : YES
• Video Adjustable : Hue /Saturation /Contrast /Brightness adjust
• PTZ Control : NO
• USB Mouse : YES
• Power Source : DC 12V
• Key Lock(Password Protection) : YES
• Power-down recovery function : YES
• Size(mm) : 259(W) x 44(H) x 221(D)
