BRAND: Tektronix

Tektronix Digital Storage Oscilloscope 70MHz 2CH, 1.0 GS/s , 7Inch Colour Display, 2.5K Point Record Length on all Channels, 8Bit Vertical Resolution, 2 mV to 200 mV/div: ±1.8 V, Time Base :2.5ns/div, 158X326X124 2.2kg

Digital Storage Oscilloscope


The TBS1000B Digital Storage Oscilloscope Series provides you with affordable performance in a compact design. Packed with standard features - including USB connectivity, 34 automated measurements, limit testing, data logging, frequency counter, trend plot and a context-sensitive help menu - the TBS1000B Series oscilloscopes helps you get more done, in less time.


  • 7 inch WVGA (800X480) Active TFT Color Display
  • 34 automated measurements
  • Dual window FFT, simultaneously monitors both the time and frequency domains
  • Built-in waveform limit and trend plot testing
  • Dual channel frequency counter
  • Zoom Function
  • Automated, extended data logging feature
  • Autoset and auto-ranging functions
  • Built-in context-sensitive help


  • Bandwidth1 : 70 MHz
  • Channels : 2
  • Sample rate on each channel : 1.0 GS/s
  • Record length : 2.5k points at all-time bases


Additional Information

Device Oscilloscope
Type Digital | Storage
