TOP T890

SKU: TOP T890

BRAND: Toptronics

In Stock
R 4,364.25_{(inc VAT)}
R 3,795.00_{(ex VAT)}

Collections: Test & Measurement

Type: Calibration Equipment

Category: Three Phase Detector

Non-Contact 3-Phase Detector 150~1000VAC , -10ºC to 50ºC , 15mA , Cable Length : Approx 800mm , Humidity 80% , CATIII

Non-Contact 3-Phase Detector

Features

3-Phase Detector (Non-contact)
Clamps over wire insulation without contact on conductor
Non-contact sensor clips
Open phase and phase sequence
Magnets on back of unit to mount on metal surfaces

Specifications

Operating Voltage : 150 to 1000V AC
Operating Frequency : 45 to 65Hz
Circuit Structure : Electronic
Operating Temperature : -10oC to 50oC
Humidity : 80%
Current Consumption : 15mA
Cable Length : Approx 800mm
Power Source : 4 x 1.5 AA Batteries
Standard Accessories : Carry Pouch
Certificates : UL, IEC61010-1. Certificate of Conformance

Downloads

Datasheet - TOP T890

Additional Information

Device	Detector
Type	Non-Contact \| 3-Phase
