10 Gbps Networking - Combined with the latest 10GBase-T Technology, TX401 delivers extreme speeds of up to 10 Gbps, which is 10× faster than typical Gigabit adapters, guaranteeing smooth data transmissions for both internet access and local data transmissions.†

Versatile Compatibility - With extreme speed and ultra-low latency, 10GBase-T is backwards compatible with Fast Ethernet and Gigabit Ethernet, automatically negotiating between higher and lower speed connections.

CAT6A Ethernet Cable - To maximize TX401's performance, a 1.5 m CAT6A Ethernet Cable is included—rated for up to 10 Gbps while a regular cable is only rated for 1 Gbps.

Low-Profile and Full-Height Brackets - In addition to the standard bracket, a low-profile bracket is provided for mini tower computer cases. Customized options give you the flexibility to find a bracket that perfectly fits your board design.Comprehensive System Support - Fully compatible with Windows 11/10/8.1/8/7, Windows Servers 2019/2016/2012 R2, and Linux to meet your diverse operating system needs.‡

• Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE802.3an, IEEE802.3az, IEEE 802.3x
• Network Media: 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-TX
• Data Rates:
• 100 Mbps, 1 Gbps, 2.5 Gbps, 5 Gbps, 10 Gbps for Half-Duplex mode,
• 200 Mbps, 2 Gbps, 5 Gbps, 10 Gbps, 20 Gbps for Full-Duplex mode
• Flow Control: 802.3x
• Interface: 1× PCI Express 3.0 x4, 1× RJ45 Gigabit/Megabit Port
• LEDs: 10 Gbps Link/Act, 5 / 2.5 / 1 Gbps and 100 Mbps Link/Act
• Dimensions: 120.8 × 98.2 × 21.5 mm (4.8 × 3.9 × 0.8 in)
• Package Contents
  • 10 Gigabit PCIe Network Adapter (TX401)
  • Standard/Low-Profile Brackets
  • Quick Installation Guide
  • Resource CD
  • 1.5 m CAT6A Ethernet Cable
• Certification : FCC, CE, RoHS
• System Requirements : Windows 10/8.1/8/7, Windows Servers 2019/2016/2012 R2, Linux‡
• Environment

  • Operating Temperature: 0°C~40°C (32°F ~104°F)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing

1. Datasheet - TP-LINK TX401
