| Camera |
| Image Sensor |
1 / 3 "CMOS |
| Image Size |
1920×1080 |
| Electronic Shutter |
1 / 3s ~ 1 / 100000s |
| Iris Type |
Fixed Iris |
| Min. Illumination |
0.02 lux @F2.0, AGC ON; 0 lux (Illumination on) |
| Lens |
2.8mm@F2.0, Horizontal FoV: 90°;Vertical FoV:50°;Diagonal FoV:103°
3.6mm@F2.0, Horizontal FoV:69°;Vertical FoV:39°;Diagonal FoV:82° |
| Focus |
Fixed |
| Lens Mount |
M12 |
| Day&Night |
ICR |
| Wide Dynamic Range |
Digital WDR |
| BLC |
Yes |
| HLC |
Yes |
| Defog |
Yes |
| Digital NR |
Yes |
| S/N Ratio |
≥50dB |
| Angle Adjustment |
Pan: 0°~360°; Tilt:0°~80°;Rotation: 0°~360° |
| DORI Distance |
| Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8mm |
46m(151ft) |
19m(61ft) |
9m(30ft) |
5m(16ft) |
| 3.6mm |
61m(200ft) |
24m(79ft) |
12m(39ft) |
6m(20ft) |
| Image |
| Video Compression |
Main stream: H.265+ / H.265 / H.264 + / H.264
Sub stream: H.265+ / H.265 / H.264 + / H.264 / MJPEG |
| H.265 Compression Standard |
Main Profile@Leve4.1 High Tier |
| Resolution |
1080P(1920×1080), 720P(1280×720), D1, 640×360,VGA(640×480), 480×240, CIF |
| Main Stream |
1080P/720P(60Hz: 1~30fps; 50Hz: 1~25fps) |
| Sub Stream |
D1/640×360/VGA/480× 240/CIF (60Hz: 1~30fps; 50Hz: 1~25fps) |
| Bit Rate |
32 Kbps ~ 3 Mbps |
| Audio Compression |
G711A/U |
| Image Settings |
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, NR, Flip horizontally/vertically, etc.
adjustable through client software or web browser |
| ROI |
Each ROI to be configured separately |
| Interfaces |
| Network |
RJ45 (10/100 Base-T) |
| Video Output |
No |
| Audio |
1CH built-in MIC |
| Storage |
No |
| Reset |
No |
| Functions |
| Remote Monitoring |
Web browser /TVT NVR/NVMS2.X/Mobile APP |
| Web Browser |
Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+ |
| Online Connection |
Support simultaneous monitoring for up to 6 users; Support multi-stream real time transmission |
| Network Protocol |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTMP, DDNS, 802.1x, HTTP, QoS, P2P |
| Interface Protocol |
ONVIF |
| API&SDK |
Yes |
| Storage |
Network remote storage |
| Motion Detection |
Support smart motion detection; filtering motion alarm triggered by other target types except people. |
| Smart Alarm |
White light alarm triggered by smart events, IP conflict, network disconnected |
| Smart Event |
(People) region intrusion/line crossing detection |
| General Function |
Watermark, video mask, heartbeat, one-click disarming |
| Security |
Video encryption, firmware encryption, configuration encryption, illegal login lock, IP address filtering,
802.1x authentication, basic and digest authentication for HTTP/RTSP |
| PoE |
Yes, IEEE802.3af |
| Supplement Light Range |
IR range: 20 ~ 30 m; white light range:10 ~ 20 m |
| Ingress Protection |
IP67 |
| Others |
| Power Supply |
PoE |
| Power Consumption |
< 5.5W |
| Operating Environment |
- 20 °C ~ 55 °C (-4°F~131°F); Humidity: less than 95 % (non-condensing) |
| Storage Environment |
- 20 °C ~ 60°C (-4°F~140°F), Humidity: less than 95 % (non-condensing) |
| Dimensions ( mm ) |
162.1 × 74.8 × 73.8 |
| Weight ( net ) |
Approx. 0.25KG |
| Installation |
Ceiling mounting; Wall mounting |
| Certificate |
CE, FCC |
| Environmental Protection |
Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006) |
