Digital Multimeter 600V AC/DC 10A, Res/Cap/Freq, Temp(℃):‒40℃~1000℃, Temp:(℉)‒40℉~1832℉, Continuity Buzzer, Diode, Display Count:6000, CATⅡ 600V, Drop Test 2M, Freq:10.00Hz~1.000MHz, NCV, Data Hold, Weight 255g
600V AC/DC 10A Digital Multimeter
Overview
UT133A series is a palm size multimeter adopting intellectual ADC chip. It provides overload alarm as well as electricity protection. It is a professional device designed for electric industry.
Features
- Over voltage/current audible alarm
- High voltage warning
- Auto power off (can be disabled)
- Low power consumption
- Fast and accurate capacitance measurement
- 2m drop proof
Specifications
| Specifications |
Range |
UT133A |
| DC voltage (V) |
600mV/6000mV/60V/600V |
±(0.5%＋3) |
| AC voltage (V) |
600V |
±(0.7%+3) |
| DC current (A) |
600uA/60mA/600mA/10A |
±(1%+3) |
| AC current (A) |
10A |
±(1.2%+3) |
| Resistance (Ω) |
600Ω/6000Ω/60kΩ/600kΩ/60MΩ |
±(0.8%+2) |
| Capacitance (F) |
9.999nF/99.99nF/999.9nF/9.999μF/99.99μF/999.9μF/9.999mF |
±(4%+5) |
| Frequency (Hz) |
10.00Hz~1.000MHz |
±(0.1%+5) |
| Temperature (℃) |
‒40℃~1000℃ |
±(1%+4) |
| Temperature (℉) |
‒40℉~1832℉ |
±(1.5%+5) |
| Features |
| Display count |
|
6000 |
| Range selection |
|
Auto |
| Diode |
|
Yes |
| Continuity buzzer |
|
Yes |
| Battery test |
Tests 1.5V and 9V batteries and
displays ‘good’, ‘low’, ‘bad’ status |
|
| NCV |
|
Yes |
| LCD backlight |
|
Yes |
| Test probe holder |
|
Yes |
| Data hold |
|
Yes |
| Low battery indication |
|
Yes |
| Overload indication |
|
Yes |
| General Characteristics |
| Power |
1.5V battery (R03) x 2 |
| Display |
56.8mm x 36.1mm |
| Product color |
Red and grey |
| Product net weight |
255g (with batteries) |
| Product size |
155mm x 76.5mm x 49mm |
| Standard accessories |
Manual, test leads, K-type thermocouple (UT133A) |
| Standard individual packing |
Gift box, English manual |
| Standard quantity per carton |
350mm x 335mm x 318mm |
| Standard carton measurement |
30pcs |
| Standard carton gross weight |
12.5kg |
Downloads
Additional Information
| Device |
Multimeter |
| Type |
600V | AC/DC | 10A | Digital |
