UNI-T UT33B+

SKU: UNI-T UT33B+

BRAND: UNI-T


Digital Multimeter 600V AC/DC 10A DC, Res:20m, Display Count:1999, Manual Range, Diode, Continuity Buzzer, Auto Power Off, Auto Backlight Off, Drop Test 2m

Overview

The new generation UT33+ series redefines the performance standards for introductory digital multimeters. Our innovative industrial design makes sure that these products can withstand 2 meters drop. The new LCD display layout provides a better user experience. The UT33+ series safety standards have also been enhanced to ensure that users can work safely in CAT ll 600V environment.

Features

  • Max display : 1999
  • Auto power off : Yes
  • Auto backlight off : Yes
  • Diode test : Yes
  • Continuity buzzer : Yes
  • Drop test : 2m
  • Test probe holder : Yes
  • Safety rating : CAT II 600V
  • Range selection : Manual
  • Battery test : 1.5V/9V/12V

General Characteristics

  • Power : AAA battery (zn-mn) 1.5Vx2
  • LCD size : 66mmx51mm
  • Product color : Red and grey
  • Product net weight : 473g
  • Product size : 131mmx95mmx58mm
  • Standard Accessories : Test lead, manual, K-type temperature probe (UT33C+ only)

Specification



  • DC voltage (V)

    • Range : 200.0mV~600V
    • Accuracy : ±(0.5%+3)

    AC voltage (V)

    • Range : 200.0V~600V
    • Accuracy : ±(1.2%+3)

    DC current (A)

    • Range : 200.0μA~10.00A
    • Accuracy : ±(1.0%+3)

    AC current (A)

    • Range : 200.0μA~10.00A
    • Accuracy : NA

    Resistance (Ω)

    • Range : 200.0Ω~20.00MΩ
    • Accuracy : ±(0.8%+2)

    Capacitance (F)

    • Range : 2.000nF~2.000mF
    • Accuracy : NA
