600V AC/DC Digital Insulation Resistance Tester with 4 Test Voltage Ranges
Overview
Features
Auto Range
Auto Power Off
Secondary Display
Low Battery Indication
Data Logging
Comparison
Polarization Index(PI)
Dielectric Absorption (DAR)
USB Interface
LCD Backlight
Analogue Bar Graph
Over Range Warning
High Voltage Indication
Timer : Around 15 minutes
Specification
Insulation Resistance(Ω)
Test Voltages : 500V/1000V/2500V/5000V; 0%~20% Accuracy
500V : 0.0MΩ~20GΩ; ±(3%+5) Accuracy
1000V : 0.0MΩ~40GΩ; ±(3%+5) Accuracy
2500V : 0.0MΩ~100GΩ; ±(3%+5) Accuracy
5000V : 0.0MΩ~1000GΩ; ±(3%+5) Accuracy
Short Circuit Current : >3.0mA
DC Voltage : 600V ±(2%+3)
AC Voltage : 600V ±(2%+3)
General Characteristic
Power : 1.5V Alkaline Batteries (LR14) x 8
LCD Size : 123mm x 58mm
Product Color : Red & Grey
Product Net Weight : 2Kg
Product Size : 202mm×155mm×94mm
Standard Accessories : 2PCs of one plug test lead to one alligator clip(Black and Green),1 PC of two plugs test lead to one alligator clip(Red), Batteries, Tool Box, USB Cable,PC Software CD, Power Adaptor
Standard Individual Packing : Gift Box, English Manual
Standard Quantity Per Carton : 4 PCs
Standard Carton Measurement : 525mm x 335mm x 345mm (0.061CBM Per Standard Carton)
Standard Carton Cross Weight : 19Kg
Discover the UNI-T UT513A Digital Insulation Resistance Tester, designed for precision with 600V AC/DC testing capabilities across four voltage ranges. Enjoy features like auto range, data logging, and a backlit LCD for easy use in low light. Ideal for electricians and maintenance professionals, this tester ensures reliable results and enhanced safety for all your electrical projects.
