FM-MPX Demodulator DIP16
Specifications
-
- Device Type: FM Intermediate Frequency (IF) Amplifier and Detector
- Package Type: DIP-16
- Application: FM radio tuner and receiver circuits
General Features
- Complete FM IF processing IC
- Integrated IF amplifier stages
- FM detector circuit included
- Built-in limiter amplifier
- Meter drive output for signal strength indication
- Low external component count
- Designed for FM broadcast receivers
Electrical Characteristics
- Supply Voltage (VCC):
- 4.5 V to 12 V
- Typical: 8 V
- Supply Current:
- Operating Frequency:
Internal Functions
- Multi-stage IF amplifier
- Limiter amplifier
- Quadrature FM detector
- Signal strength output
- Audio output stage
- Automatic Gain Control (AGC) functions
Performance Characteristics
- High IF gain
- Excellent AM noise suppression
- Good limiting characteristics
- Low distortion FM demodulation
- High sensitivity reception
- Stable operation over temperature
Outputs
- Recovered audio output
- Signal strength meter output
- AGC control output
- Detector output
Package Information
- Package Type: DIP
- Pin Count: 16 Pins
- Mounting Style: Through-Hole
Operating Temperature
Typical Applications
- FM radio receivers
- Stereo tuners
- Portable radios
- Car radio systems
- Communications receivers
- Hi-Fi tuner equipment
- Consumer audio products
Additional Information
Enhance your FM radio projects with the UPC1197C FM-MPX Demodulator. This versatile DIP-16 IC offers high sensitivity reception, low distortion, and integrated functions for seamless FM IF processing. Ideal for radios, tuners, and audio systems, it ensures excellent sound quality and reliable performance. Upgrade your audio experience effortlessly with this compact and efficient solution.
