UPC1200V

• Device Type: Monolithic AF Power Amplifier
• Package Type: ZIP-12 / SIP Power Package
• Application: Consumer audio equipment, televisions, radios, and portable sound systems

Electrical Characteristics

• Supply Voltage Range (VCC):
  • 6 V to 18 V
• Recommended Supply Voltage:
  • 12 V to 14.4 V
• Quiescent Current:
  • Approximately 40 mA typical

Audio Performance

• Output Power:
  • 5 W typical @ 13.2 V, 4 Ω load
  • Up to 7 W maximum under optimum conditions
• Load Impedance:
  • 4 Ω to 8 Ω speakers
• Total Harmonic Distortion (THD):
  • Typically < 0.5%
• Frequency Response:
  • 20 Hz to 20 kHz

Protection Features

• Thermal shutdown protection
• Output short-circuit protection
• Safe Operating Area (SOA) protection
• Overload protection

Package Information

• Package Type: ZIP/SIP Power Package
• Pin Count: 12 Pins
• Mounting Style: Through-Hole
• Requires heatsink for full-power operation

Operating Temperature

• Operating Range:
  • -20°C to +75°C
• Storage Temperature:
  • -40°C to +125°C

Typical Applications

• Television audio output stages
• Portable radios
• Cassette players
• Intercom systems
• Small PA systems
• Active speakers
• Consumer audio products
