PowerControl & PowerAssist

Yes

Transfer switch

32 A

Maximum AC input current

32 A

DC input voltage range

12 V: 9.5–17 V / 24 V: 19–33 V / 48 V: 38–66 V

Output voltage

230 VAC ±2%

Frequency

50 Hz ±0.1%

Continuous output power @ 25°C

3000 VA

Continuous output power @ 25°C

2400 W

Continuous output power @ 40°C

2200 W

Continuous output power @ 65°C

1700 W

Max. apparent feed-in power

3000 VA

Peak power

5500 W

Maximum efficiency

93% / 94% / 95%

Zero-load power

13 / 13 / 11 W

Zero-load power in AES mode

9 / 9 / 7 W

Zero-load power in Search mode

3 / 3 / 2 W

AC input voltage range

187–265 VAC

Input frequency

45–65 Hz

Charge voltage – Absorption

14.4 V

Charge voltage – Float

13.8 V

Storage mode

13.2 V

Maximum battery charge current

120 A / 220 A

Battery temperature sensor

Included

Auxiliary output

Yes – 32 A / 50 A

External AC current sensor

Optional, 100 A

Programmable relay

Yes

Protection

a–g

VE.Bus communication port

For parallel and three-phase operation, remote monitoring and system integration

General-purpose communication port

Yes, 2×

Remote on-off

Yes

Operating temperature range

-40°C to +65°C (fan-assisted cooling)

Humidity

Maximum 95% RH, non-condensing

Maximum altitude

2000 m

Material & colour

Steel, blue RAL 5012

Protection category

IP22

Battery connection

M8 bolts; four M8 bolts (2 plus and 2 minus connections)

230 VAC connection

Screw terminals 13 mm² (6 AWG) / M6 bolts

Weight

19 kg / 33 kg / 30 kg / 30 kg / 42 kg / 49 kg / 80 kg

Dimensions (H × W × D)

546 × 275 × 147 mm; 499 × 268 × 141 mm; 702 × 345 × 152 mm; 607 × 330 × 149 mm; 565 × 320 × 149 mm; 642 × 363 × 206 mm; 677 × 363 × 206 mm; 810 × 405 × 217 mm
