VICT PHOENIX INVERTER 12V/1200
SKU: VICT PHOENIX INVERTER 12V/1200
BRAND: Victron
R 4,395.00 (inc VAT) R 3,821.74 (ex VAT)
🚚
Delivery time: 2-5 working days for South Africa
✓
In stock - Ready for immediate dispatch
Free shipping for orders over ZAR 1,000.00
Victron Phoenix Pure Sine Wave Inverter 12V 1200VA 1000/850W, Peak Power 2200W, VE.Direct, Battery Connection: Screw Terminals, Max Cable Cross Section: 35/25/25mm² /AWG2 / 4 / 4, Without Battery Charger , IP21, 7.4Kg
Phoenix Pure Sine Wave Inverter
Specifications
Cont. power at 25°C (1) : 1200VA
Cont. power at 25°C / 40°C : 1000 / 850W
Peak power : 2200W
Output AC voltage / frequency (adjustable) : 230VAC or 120VAC +/- 3% 50Hz or 60Hz +/- 0,1%
Input voltage range : 9,2 - 17 / 18,4 - 34,0 / 36,8 - 62,0V
DC low shut down (adjustable) : 9,3 / 18,6 / 37,2V
Dynamic (load dependent) DC low shut down (fully configurable) Dynamic cut-off, see https://www.victronenergy.com/live/ve.direct:phoenix-inverters-dynamic-cutoff
DC low restart and alarm (adjustable) : 10,9 / 21,8 / 43,6V
Battery charged detect (adjustable) : 14,0 / 28,0 / 56,0V
Max. efficiency : 91 / 91 / 92%
Zero-load power : 7 / 8 / 10W
Default zero-load power in ECO mode (default retry interval: 2,5 s, adjustable) : 1 / 1,5 / 3,0W
ECO mode stop and start power setting : Adjustable
Protection (2) : a - f
Operating temperature range : -40 to +65°C (fan assisted cooling) Derate 1,25% per °C above 40°C
Humidity (non-condensing) : max 95%
ENCLOSURE
Material & Colour : Steel chassis and plastic cover (blue Ral 5012)
Battery-connection : Screw terminals
Maximum cable cross-section : 35 / 25 / 25mm2 / AWG2 / 4 / 4
Standard AC outlets :
230V: Schuko (CEE 7/4), IEC-320 (male plug included)
UK (BS 1363), AU/NZ (AS/NZS 3112)
120V: Nema 5-15R, GFCI
Protection category : IP 21
Weight : 7,4kg / 16,3lbs
Dimensions (h x w x d, mm) (h x w x d, inch) : 117 x 232 x 327, 4.6 x 9.1 x 12.9 (12V model: 117 x 232 x 362)
ACCESSORIES
Remote on-off : Yes
Automatic transfer switch : Filax
Downloads
Additional Information
Device
Inverter
Type
Phoenix | Pure Sine Wave
Power your devices with confidence using the VICT Phoenix Inverter 12V/1200. Delivering a pure sine wave output of 1200VA and peak power of 2200W, this inverter ensures efficient and reliable power supply for all your needs. Its compact design and high efficiency make it perfect for both home and outdoor use. Enjoy peace of mind with adjustable settings and robust protection features.
