R7FA4 Plus a Development Board, Based on R7FA4M1AB3CFM, Compatible with Arduino UNO R4 MINIMA.
R7FA4 Plus Development Board
Overview
The R7FA4 Plus development platform provides users with an economical, flexible and convenient way to realize more creative ideas. On the hardware, it features Renesas Electronics' powerful 32-bit microcontroller R7FA4M1AB3CFM, which has expanded memory, peripherals, and faster clocks, enabling it to easily handle complex projects.
Features
Based on R7FA4M1AB3CFM, and is compatible with Arduino UNO R4 Minima.
Utilizes Renesas Electronics' RA4M1 (Arm® Cortex®-M4) microcontroller, with a main frequency of 48MHz.
Equipped with 256 kB Flash and 32 kB RAM, the expanded memory can easily handle complex projects.
The R7FA4 Plus development board adds a 12-bit DAC, CAN bus and operational amplifiers, providing expanded functionality and flexibility for designs.
Onboard 5V/3.3V headers for easy voltage switching, allowing the use of more expansion modules.
Flexible power options, supporting USB-C power supply or external input power VIN (6V<=VIN<=24V).
Onboard power indicator (PWR), USER LED, serial port receive indicator (RX) and transmit indicator (TX), making it easy to monitor the working status of the development board.
Onboard ICSP interface, can be used as an SPI interface.
Supports user soldering of corresponding interface insertion into the experimental board.
Specifications
MICROCONTROLLER
R7FA4 (32-bit ARM Cortex-M4)
CLOCK FREQUENCY
R7FA4: 48MHz
STORAGE
R7FA4: 256kB Flash, 32kB RAM
WIRELESS COMMUNICATION
None
OPERATING VOLTAGE
Options for 5V/3.3V, support more shields
POWER INPUT
6~24V
RESET BUTTON
Lateral, easier to use when connecting with shield
IO PIN OUTPUT CURRENT
8mA
DIGITAL PINS
14
ANALOG PINS
6
DAC
2
PWM
6
UART
1
I2C
1
SPI
1
CAN
1
DC JACK
Low profile, shields won't be blocked anymore while connecting
POWER OUTPUT HEADER
Provides 5V OR 3.3V power output and common-grounding with other boards
5V POWER OUTPUT
Up to 2000mA Max, features higher driving capability
EXPERIMENTAL BOARD
Support, the solder pad is provided for DIY interfaces to connect with the experimental board
Unlock your creativity with the WVS UNO REV 4 MINIMA, featuring a powerful R7FA4M1AB3CFM microcontroller. This versatile development board is compatible with Arduino UNO R4 MINIMA and offers expanded memory, flexible power options, and enhanced functionality for complex projects. Perfect for DIY enthusiasts and professionals alike, it simplifies your design process and elevates your projects to new heights.
