Schneider Emergency Off Push Button, Harmony XB4, Metal, Red Mushroom 40mm, 22mm, Trigger Latching Turn to Release, 1NC
Emergency Off Push Button
Overview
This Harmony XB4 emergency stop / shutdown 40mm mushroom head modular red push button operates with a latched turn to release mechanism. It has a metal bezel. This emergency stop / shutdown button, also called EMS (Emergency Machine Stop) and EMO (Emergency Off), is easily installed into a standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance thanks to a clear color and a prominent 40mm mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments.
Specifications
|
Main
|
|
Range of product
|
Harmony XB4
|
|
Product or component type
|
Emergency switching off push-button
Emergency stop push-button
|
|
Device short name
|
XB4
|
|
Bezel material
|
Chromium plated metal
|
|
Fixing collar material
|
Zamak
|
|
Mounting diameter
|
22.5 mm
|
|
Sale per indivisible quantity
|
1
|
|
Shape of signaling unit head
|
Round
|
|
Type of operator
|
trigger action and mechanical latching
|
|
Head type
|
Standard
|
|
Reset
|
Turn to release
|
|
Operator profile
|
Red mushroom Ø 40 mm, unmarked
|
|
Contact operation
|
Slow-break
|
|
Connections - terminals
|
Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1
Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to IEC 60947-1
|
Downloads
Additional Information
| Device |
Switch |
| Type |
Emergency Off | Push Button |
Ensure safety in your workspace with the Schneider Harmony XB4 Emergency Off Push Button. This durable, metal red mushroom button features a 40mm head for quick recognition and a reliable turn-to-release mechanism, perfect for harsh environments. Easy to install and designed for immediate access, it’s your essential solution for emergency shutdowns.
