XY-CC290-4P-1N

Name: XY-CC290-4P-1N - Communica [Part No: XY-CC290-4P-1N]
Brand: Weipu
SKU: XY-CC290-4P-1N
Price: 129.40 ZAR
Availability: InStock

SKU: XY-CC290-4P-1N

BRAND: Weipu

In Stock
R 148.81_{(inc VAT)}
R 129.40_{(ex VAT)}

Collections: Connectors

Type: Circular Connectors

Category: Power Connectors IP67 and IP68

Circular Connector Plastic IP68 Screw Lock Cable End Plug 4 Pol Male Solder Termination 25A CABLE OD=13-16MM (NO CAP)

Circular Connector Plastic IP68 Screw Lock Cable

Feature(s)

Coupling: Threaded
Shell material: PC, Nylon66, fire resistance: V-0
Insert material: PPS, max temperature 260 ℃
Contact material: Brass with gold plating
Termination Solder: SP13, SP17, SP21, SP29
Crimp: SP17, SP21, SP29
Screw: SP21, SP29 ( Ø2.5, Ø3, Ø3.5mm contact)
Cable outer diameter range: SP11: 4-6.5mm
SP13 I: 4-6.5mm, II: 5-8mm
SP17: 6-10mm
SP21 I: 4.5-7mm, II: 7-12mm
SP29: 13-16mm
IP rating: IP68
Mating cycle: 500
Temperature range-40 ~ + 85℃
Insulation resistance: 2000 MΩ
Rated Current (A): 25
Contact Diameter (mm): Ø2.5X7
Rated Voltage (AC. V): 500
Tested voltage (AC. V) 1: 1500
Contact resistance(MΩ): 1
Termination: Solder/Screw
Wire size(mm²/AWG) : ≤4/11
Wire Size For Screw Termination: ≤1.5/15

Additional Information

Device	Connector
Type	Screw Lock Cable \| Male Solder Termination
