XY3106A-22-12S

Name: XY3106A-22-12S - Communica [Part No: XY3106A-22-12S]
Brand: Xytron
SKU: XY3106A-22-12S
Price: 1058.32 ZAR
Availability: OutOfStock

SKU: XY3106A-22-12S

BRAND: Xytron

Sold Out
R 1,217.07_{(inc VAT)}
R 1,058.32_{(ex VAT)}

Collections: Connectors

Type: MIL-Spec / MIL-Type

Category: Circular MIL DTL-5015/C-5015 Connectors

Circular Connector MIL-DTL-5015 Style Screw Lock Cable End Plug Optional Cable Clamp 5 Pole 3x #16/2x #8 Contacts. Female Solder. 13A/46A 200VAC/250VDC (MS3106A22-12S)(97-3106A-22-12S)

MIL-DTL-5015 Circular Connector

Specifications

RoHS:	N
Number of Positions:	5 Position
Contact Gender:	Socket (Female)
Insert Arrangement:	22-12
Product:	Plugs
Shell Size:	22
Shell Style:	In-Line
MIL Type:	MIL-DTL-5015
Termination Style:	Solder
Mounting Style:	Free Hanging
Current Rating:	13 A, 46 A
Contact Plating:	Silver
Contact Material:	Copper Alloy
Series:	MS 5015
Brand:	Amphenol Industrial
Mating Style:	Bayonet
Mounting Angle:	Straight
Product Type:	Circular MIL Spec Connector
Shell Material:	Aluminum Alloy
Shell Plating:	Olive Drab Zinc
Subcategory:	Circular Connectors
Tradename:	5015
Wire Gauge:	10 AWG to 8 AWG, 22 AWG to 16 AWG

Additional Information

Device	Connector
Type	MIL-DTL-5015 \| Circular
