USR W610 1-PORT SERIAL TO WIFI

Name: USR W610 1-PORT SERIAL TO WIFI - Communica [Part No: USR W610 1-PORT SERIAL TO WIFI]
Brand: UsrIoT
SKU: USR W610 1-PORT SERIAL TO WIFI
Price: 1060 ZAR
Availability: OutOfStock

SKU: USR W610 1-PORT SERIAL TO WIFI

BRAND: UsrIoT

Sold Out
R 1,219.00_{(inc VAT)}
R 1,060.00_{(ex VAT)}

Collections: Computing & Peripherals

Type: Industrial IoT Wi-fi Solutions

Category: RS485 to WiFi Converter

The Industrial USR-W610 is both an RS485 to WiFi Converter and an RS232 to WiFi Converter, Which can realize the Bi-Directional Transparent Data Transmission between RS232/RS485, WiFi and Ethernet

W610 RS485 to WiFi Converter

Overview

The USR-W610 is an industrial serial to WiFi converter, which can realize the bi-directional transparent data transmission between RS232/RS485, WiFi and Ethernet. Through simple configuration via Web Server or setup software can assign working details, realize serial data and TCP/IP data package transparent transmission by converter.

Features

1-port RS-232 or RS485 to 802.11 b/g/n WLAN serial device server
Links serial and Ethernet devices to an IEEE 802.11b/g/n network
Supports TCP server/client, UDP server/client,https client, Virtual COM
Supports Modbus RTU to Modbus TCP
Supports multiple networking mode with 1 RJ45 ethernet port

Specifications

Categories	Cellular & Network Communication
Manufacturer/Brand	USR IOT
Wi-Fi Standard	802.11b/g/n
Ethernet ports	LAN/WAN
Ethernet Protocols	10/100 Mbps
Frequency	2.4Ghz
Serial Standard	RS232, RS485
Comm. Method	Ethernet, Serial, WiFi
Comm. Protocol	ARP, DHCP, DNS, HTTP, HTTPD Client, ICMP, IP, Modbus RTU, Modbus TCP, TCP, UDP, Web socket
Supply Voltage	5-36 Vdc
Operating Temperature	-40° to 85°C, -40° to 185°F
Width (in)	3.25
Depth (in)	0.99
Height (in)	3.39
Width (mm)	82.50
Depth (mm)	25.00
Height (mm)	86.00
Weight (kg)	0.567
Weight (lbs)	1.25
Safety Approvals	FCC, RoHS
Safety Standards	CE

Downloads

Additional Information

Device	Converter
Type	W610 \| RS485 to WiFi
References	USR IOT
