• ANSI/TIA Category : 6
• Contact Resistance Variation, maximum : 20mΩ
• Contact Resistance, maximum : 100mΩ
• Current Rating : 1.5A
• Dielectric Withstand Voltage, RMS, conductive surface : 1500VAC @ 60Hz
• Dielectric Withstand Voltage, RMS, contact­ to­ contact : 1000VAC @ 60Hz
• Insulation Resistance, minimum : 500MΩ

Environmental Specifications

• Flammability Rating : UL94 V­0
• Operating Temperature : ­10°C to 60°C
• Relative Humidity : Up to 95%, non­-condensing
• Safety Standard : cUL | UL
• Storage Temperature : 40°C to 70°C

General Specifications

• Cable Type : U/UTP (unshielded)
• Color : White

Mechanical Specifications

• Conductor Gauge, Solid : 22 AWG | 24 AWG
• Conductor Gauge, Stranded : 22 AWG | 24 AWG
• Conductor Type : Solid | Stranded (7 strands)
• Material Type : Copper alloy | High­ Impact, Flame Retardant, Thermoplastic
• Outlet/Module Contact Plating : Precious Metals
• Plug Insertion Life, minimum : 750 Times
• Plug Insertion Life, test plug : IEC 60603­7 compliant plug
• Plug Retention Force, minimum : 30 lbf | 133 N
• Rear Termination Contact Plating : Nickel
• Rear Termination Type : IDC
• Wiring : T568A | T568B
