XY3106A-20-17S

Name: XY3106A-20-17S - Communica [Part No: XY3106A-20-17S]
Brand: Amphenol
SKU: XY3106A-20-17S
Price: 485.25 ZAR
Availability: InStock

SKU: XY3106A-20-17S

BRAND: Amphenol

In Stock
R 558.04_{(inc VAT)}
R 485.25_{(ex VAT)}

Collections: Connectors

Type: MIL-Spec / MIL-Type

Category: Circular MIL DTL-5015/C-5015 Connectors

Circular Connector MIL-DTL-5015 Style Screw Lock Cable End Plug Optional Cable Clamp 6 Pole 1x #16/5x #12 Contacts. Female Solder. 13A/23A 500VAC/700VDC (MS3106A20-17S)(97-3106A-20-17S)

MIL-DTL-5015 Circular Connector

Specifications

RoHS:	N
Number of Positions:	6 Position
Contact Gender:	Socket (Female)
Insert Arrangement:	20-17
Product:	Plugs
Shell Size:	20
Shell Style:	In-Line
MIL Type:	MIL-DTL-5015
Termination Style:	Solder
Mounting Style:	Free Hanging
Current Rating:	13 A, 23 A
Contact Plating:	Silver
Contact Material:	Copper Alloy
Series:	MS 5015
Brand:	Amphenol Industrial
Mating Style:	Bayonet
Mounting Angle:	Straight
Product Type:	Circular MIL Spec Connector
Shell Material:	Aluminum Alloy
Shell Plating:	Olive Drab Zinc
Subcategory:	Circular Connectors
Tradename:	5015
Wire Gauge:	14 AWG to 12 AWG, 22 AWG to 16 AWG

Additional Information

Device	Connector
Type	MIL-DTL-5015 \| Circular
