SITRANS P320 Pressure Transmitter With Custom Configuration
SITRANS P320 Pressure Transmitter
Specifications
Manufacturer: Siemens
Product family: SITRANS P320
Type: Differential pressure and flow transmitter
Measurement type:
Differential pressure
Flow measurement
Communication protocol:
PROFIBUS PA
Pressure rating:
PN160
Measuring cell filling:
Silicone oil
Maximum measuring span:
1600 mbar (643 inH₂O)
Process connection:
Oval flange connection
Fastening thread:
M10 (PN160)
M12 (PN420)
Wetted parts material:
Stainless steel 316L / 1.4404
Seal diaphragms: Stainless steel 316L
Sensor flange material:
Stainless steel 316 / 1.4408
Housing material:
Die-cast aluminum housing
Device design:
Dual chamber design
Explosion protection:
Intrinsic safety approved
Electrical connection:
2 × M20 × 1.5 cable entries
Display:
Integrated local display
Glass window cover
Option A00:
Cable gland and sealing plug attached (plastic)
Option E47:
ATEX (Europe)
IECEx (International)
UKEX (United Kingdom) approvals
Option H02:
Stainless steel mounting bracket (1.4301 / 304)
Communication features:
PROFIBUS PA diagnostics
Remote parameterization and monitoring
Protection features:
Industrial EMC protection
Intrinsic safety protection
Overpressure resistant construction
Mounting type:
Process mounting with oval flange
Operating temperature:
Industrial process environment rated
Applications:
Industrial automation
Oil & gas systems
Chemical plants
Water treatment systems
Differential pressure flow systems
Hazardous industrial environments
Additional features:
High accuracy process measurement
Remote configuration capability
Suitable for PROFIBUS PA process networks
Additional Information
Device
Transmitter
Type
SITRANS | P320 | Pressure | Transmitter
Upgrade your monitoring with the SITRANS P320 Pressure Transmitter, designed for precise differential pressure and flow measurement. Featuring a robust stainless steel construction, it ensures durability and reliability in demanding environments. Enjoy seamless integration with PROFIBUS PA and enhanced safety features, making it the ideal choice for industrial applications.
