1594BWBK - Plastic Enclosures - 623980564227

1594BWBK

Name: 1594BWBK - Communica [Part No: 1594BWBK]
Brand: Hammond
SKU: 1594BWBK
Price: 255 ZAR
Availability: InStock

SKU: 1594BWBK

BRAND: Hammond

R 293.25_{(inc VAT)}
R 255.00_{(ex VAT)}

🚚

Delivery time: 2-5 working days for South Africa

✓

In stock - Ready for immediate dispatch

Free shipping for orders over R1,000.00

Collections: Enclosures

Type: Plastic Enclosures

Category: ABS Plastic

Polystyrene Enclosure 81X56X40 Grey Water-Tight

Heavy Duty Enclosure

Feature(s)

Rugged electronic instrument enclosures, ideally suited for mounting printed circuit boards.
Heavy duty, thick wall design with an average wall thickness of .13” (3.3 mm).
Also suited for vertical or horizontal mounting of printed circuit boards (using optional P.C. card guides - see accessories below).
Molded from flame retardant ABS plastic (material carries a UL flammability rating of 94V-0).
Interior of each enclosure part is specially masked and sprayed with an RFI/EMI copper conductive coating (see photo above).
Coating manufacturer specifies an attenuation of more than 75 db from 1 Mhz. to 1 Ghz.
Designed to meet IP54.
Countersunk lid is secured with four M3 x 0.5 - 0.71” (18 mm) long, Philips machine screws threaded into integral brass bushings. Perfect for applications with repetitive assembly and disassembly are required.
Stocked in black with matte textured finish.

Specifications

Size L x W x H	3.2 in x 2.2 in x 1.1 in (81 mm x 56 mm x 28 mm)
Shipping Weight	0.17 lbs (0.08 kg)
UNSPSC	39121301
UPC	623980564227
Packaging Type	shrink wrap
Material	ABS Plastic
Color	Black
Flame Rating	UL94 V-0
IP Rating	IP65
Product Category	Enclosures
Type	Thick wall, water-tight

Downloads

Datasheet

Additional Information

Device	Enclosure
Type	Heavy Duty

Discover the 1594BWBK Heavy Duty Polystyrene Enclosure, expertly designed for rugged protection of your electronic components. This water-tight, flame-retardant enclosure features a thick wall design and superior RFI/EMI shielding, ensuring durability and reliability in any environment. Perfect for PCB mounting, it simplifies assembly with its secure countersunk lid. Elevate your project’s safety and performance with this top-tier enclosure.
